Mechanical Splicing Coupler
- TIANJIN
- T/T
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | CABR | |
| Model Number | 16-50mm | Material | Other, Stainless Steel, 45#Steel |
Product Description
Specifications
1) CABR High Quality Parallel Threaded Coupler2) 100% Bar Break Performance
CABR 45# Carbon Steel Parallel Thread Mechanical Rebar Coupler
CABR 45# Carbon Steel Parallel Thread Mechanical Rebar Coupler is a parallel thread mechanical splicing system designed for the connection of concrete reinforcing bars from Φ16~Φ50.
Credible: CABR stands for China Academy of Building Research, the ONLY government company and also institute company engaged in rebar mechanical splice.
Technique authority: CHIEF EDITOR of Chinese Rebar Mechanical Splice Standards including JGJ107-2010. Provide the whole technical support, training and after-sales service.
Experience: research on rebar mechanical splice since 1987.
*Designed and manufactured in compliance with ACI318, JGJ107, UBC 1997, BS8110, NF35-20-1, DIN1045, ISO 15835.
*Full-Tension splice, bar break under tensile tests.
*Easy operation, installation and maintainance.
*Full traceability of material origin and production batch.
2. Product Type
2.1 SYS A: Parallel Thread Rebar Splicing with Cold Upsetting End
(1) Cutting
(2) Cold upsetting
(3) Threading
Bar Dia.(mm) | OD (mm) | Length(mm) | Weight (kg) |
16 | 26 | 32 | 0.09 |
18 | 30 | 36 | 0.11 |
20 | 33 | 40 | 0.15 |
22 | 35 | 44 | 0.18 |
25 | 40 | 50 | 0.27 |
28 | 46 | 56 | 0.42 |
32 | 50 | 64 | 0.53 |
36 | 58 | 72 | 0.90 |
40 | 64 | 80 | 1.08 |
2.2 SYS B: Parallel Thread Rebar splicing with Rolled Thread End
(1) Cutting
(2) Stripping the rib and rolling thread
Bar Dia.(mm) | OD (mm) | Length(mm) | Weight (kg) |
16 | 24 | 38 | 0.07 |
18 | 27 | 41 | 0.13 |
20 | 29.5 | 45 | 0.15 |
22 | 32.5 | 49 | 0.19 |
25 | 37 | 56 | 0.30 |
28 | 41 | 62 | 0.43 |
32 | 47 | 70 | 0.58 |
36 | 53 | 78 | 0.93 |
40 | 58.5 | 86 | 1.25 |
50 | 73 | 106 | 2.37 |
4.Applications
5. Some Major References
India Tower(No.1 in India)-INDIA Russian Federation Tower-RUSSIA
Ba Haj Stadium-ALGERIA Penang Second Bridge-MALAYSIA
