Home > Products > New Products > ACS Wire Electric Wire ASTM B415-1988
ACS Wire Electric Wire ASTM B415-1988
Negotiable
/ Ton
1 Ton(Min. Order)
- Qingdao/Ningbo/Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | HNTDDL | |
| Model Number | ACS wire | Type | Bare | |
| Application | Overhead | Conductor Material | Aluminum Clad Steel | |
| Conductor Type | Stranded | Insulation Material | Other, Bare |
Product Description
Specifications
Aluminium-clad Steel Conductor normally used as OPGW,ground wire ,messenger wire, large quantities production.Specification
ACS Conductor manufacturer with ISO9001, ISO14001
ASTM B-415 Hard-Drawn Aluminum-Clad Steel Wire
ASTM B-416 Concentric-Lay-Stranded Aluminum-Clad Steel Conductors
Application
It is widely used in long-span transmission line, overhead ground conductor, extra high voltage overhead conductor, optical fiber composite overhead ground line, self-damping conductor line, etc.
ASTM B415-1998
ALUMINIUM CLAD STEEL WIRE
| Nominal Diameter | Area | Min. Tensile Strength | Calculated Breaking Load | Min. Coating Thickness | Max. D.C. Resistance at 20°c | Weight | |
| mm | AWG | mm² | mpa | kN | mm | Ω/km | kg/km |
| 2.052 | 12 | 3.307 | 1340 | 4.5 | 0.103 | 25.64 | 21.80 |
| 2.304 | 11 | 4.169 | 1340 | 5.6 | 0.115 | 20.34 | 27.49 |
| 2.589 | 10 | 5.260 | 1340 | 7.1 | 0.130 | 16.12 | 34.66 |
| 2.904 | 9 | 6.633 | 1340 | 8.9 | 0.145 | 12.78 | 43.65 |
| 3.264 | 8 | 8.367 | 1340 | 11.2 | 0.163 | 10.14 | 55.14 |
| 3.477 | 7 | 9.495 | 1310 | 12.4 | 0.174 | 8.93 | 62.57 |
| 3.665 | 7 | 10.55 | 1280 | 13.5 | 0.183 | 8.04 | 69.48 |
| 3.934 | 6 | 12.16 | 1240 | 15.1 | 0.197 | 6.93 | 80.13 |
| 4.115 | 6 | 13.30 | 1210 | 16.0 | 0.206 | 6.38 | 87.62 |
| 4.392 | 5 | 15.15 | 1170 | 17.7 | 0.220 | 5.60 | 99.84 |
| 4.620 | 5 | 16.76 | 1140 | 19.1 | 0.231 | 5.06 | 110.50 |
| 4.775 | 4 | 17.91 | 1100 | 19.7 | 0.239 | 4.73 | 118.0 |
| 5.189 | 4 | 21.15 | 1070 | 22.6 | 0.259 | 4.01 | 139.34 |
