Shot Blasting Cleaning Machine

FOB Price

US$ 30,000 - 400,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1. For ship, automobile and rolling stock do surface derusting.
2. For bridge steel plate, section bar and machinery and etc.

Serial number	Type Item		Q698	Q6912	Q6915	Q6920	Q6925	Q6930	Q6940
1	Effective cleaning width	mm	800	1200	1500	2000	2500	3000	4000
2	Inlet opening dimension	mm	800*1600	1200*400	1500*400	2000*400	2500*800	3000*800	4000*400
3	Length of cleaning piece	mm	1200--12000	1200--6000	1200--12000	1200*12000	3000--12000	2400--12000	4500--18000
4	Roller speed (Stepless speed reulation)	m/min	0.5--4	0.5--4	0.5--5	0.5--4	0.5—4.5	0.5--4	2—8
5	Thickness of cleaning steel plate	mm	3--60	3--60	1.5--60	3--60	3--60	3--110	4.5--100
6	Treated section bars specification		Diameter:: 16--28	[<=20#<<=16#	[<=20#<<=16#	[<=20#<<=16#		608—3001000
7	Blasting capacity	Kg/min	8*120	4*250	4*250	6*250	6*250	6*360	8*360
8	First charge weight	kg	4000	4000	4000	4500	4500	8000	11000
9	Adjusting height of rolling brush	mm	4000	200	350	450	600	850	900
10	Ventilation capacity	M3/h	22000	17560	19000	19550	27758	28050	38000
11	Outline dimensions	mm	250174250 9015	1218042507095	152005370 6797	3065068509095	3120068509095	4404263857758	45000783011117
12	Pit depth	mm	1937	1616	2257	2800	2353	2800	4370
13	Total power (Excluding dedusting)	kw	90	78.3	113.5	156.6	224.55	204.8	293.6
