Abrator for Foundry
- Qingdao
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Powerful | |
| Model Number | Q69 | Fuel | Electric | |
| Certification | Other, ISO9001 | Use | Other, Surface cleaning | |
| Cleaning Process | Other, Steel shot | Cleaning Type | Other, Automatic | |
| Industry Used | Other, Workpiece | Material | Metal / Coil |
Product Description
Specifications
1.Suitable for ship, automobile and rolling stock do surface derusting.2.for bridge and machinery and etc.
Serial number | Type Item | Q698 | Q6912 | Q6915 | Q6920 | Q6925 | Q6930 | Q6940 | |
1 | Effective cleaning width | mm | 800 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
2 | Inlet opening dimension | mm | 800*1600 | 1200*400 | 1500*400 | 2000*400 | 2500*800 | 3000*800 | 4000*400 |
3 | Length of cleaning piece | mm | 1200--12000 | 1200--6000 | 1200--12000 | 1200*12000 | 3000--12000 | 2400--12000 | 4500--18000 |
4 | Roller speed (Stepless speed reulation) | m/min | 0.5--4 | 0.5--4 | 0.5--5 | 0.5--4 | 0.5—4.5 | 0.5--4 | 2—8 |
5 | Thickness of cleaning steel plate | mm | 3--60 | 3--60 | 1.5--60 | 3--60 | 3--60 | 3--110 | 4.5--100 |
6 | Treated section bars specification |
| Diameter:: 16--28 | [<=20#<<=16# | [<=20#<<=16# | [<=20#<<=16# |
| 60*8—300*1000 |
|
7 | Blasting capacity | Kg/min | 8*120 | 4*250 | 4*250 | 6*250 | 6*250 | 6*360 | 8*360 |
8 | First charge weight | kg | 4000 | 4000 | 4000 | 4500 | 4500 | 8000 | 11000 |
9 | Adjusting height of rolling brush | mm | 4000 | 200 | 350 | 450 | 600 | 850 | 900 |
10 | Ventilation capacity | M3/h | 22000 | 17560 | 19000 | 19550 | 27758 | 28050 | 38000 |
11 | Outline dimensions | mm | 25017*4250 *9015 | 12180*4250*7095 | 15200*5370 *6797 | 30650*6850*9095 | 31200*6850*9095 | 44042*6385*7758 | 45000*7830*11117 |
12 | Pit depth | mm | 1937 | 1616 | 2257 | 2800 | 2353 | 2800 | 4370 |
13 | Total power (Excluding dedusting) | kw | 90 | 78.3 | 113.5 | 156.6 | 224.55 | 204.8 | 293.6 |
