Home > Products > Backhoe loader > New Cheap Small Backhoe Loader
New Cheap Small Backhoe Loader
- 50 Unit / Units per Month
- lianyungang/qingdao/shanghai
- T/T
You May Like
Product Details
| Condition | New | Brand Name | KAT | |
| Model Number | WZ30-25 | Type | Backhoe Loader | |
| Moving Type | Wheel Loader | Dimension(Long * Breadth * High) | 7077*2350*2700 | |
| Rated Load | 2500kg | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
Backhoe loaderModel:WZ30-25
DEUTZ:WP4G95E221
CARRARO Synchronization shift,electric-hydraulic control
CARRARO braking axle
Backhoe loader
Model: WZ30-25
DEUTZ TD226B
CARRARO synchronization shift, electric-hydraulic control
CARRARO braking axle
Main Performance:
1.Backhoe loaders exclusive use chassis, compact structure, rationally distributed.
2.Equipped with totally enclosed ROPS cab with broad vision and attractive outline design, it is comfort and reasonable to control the machine with its full range and humanization design in control system.
3.Adopt the Weichai DEUTZ engine, which is green environmental protection, high power, less fuel consumption, high working efficiency, low use cost.
4.The imported professional digging/loading transmission system from Italy, and Chinese top brand hydraulic systems enable the high stability, and the machines performance could reach the international advanced level.
5.Excellent digging/loading performance brings the best return on customers investment.
6.The imported driving axle with differential lock and wet-type brake ensure the hauling ability and safety performance. Big steering angle and big oscillating angle of swing steering axle ensure the high steering ability. Driving brake and parking brake system adopt the self-regulating, full-regulating wet-type brake with free-maintenance.
7.Optional two-wheel drive or four-wheel drive could meet customers requirement.
8.Various optional tools could be equipped according to customers requirement.
Loading Performance
Mono lever controls booms rise and fall overturn of the loading bucket and the clutchs shift.
Automatic leveling system of loading bucket avoids material drops out, automatic reposition after dumping.
In-line arrangement double cylinder of the loading system has the superior breakout force. The loading bucket could completely turnover.
Digging Performance:
Spread wing style outriggers and mid-type excavating gear, with superior working stability.
Attached with different attachment, it could accomplish different operations, such as excavating, crumbling, skiving, etc.
Excavating control valve with six jumper valves, special designed buffer system, ensure the working process smoother and steadier.
Main Technical Parameters:
Item | Unit | Parameter | |||
Backhoe bucket capacity | m3 | 0.3 | |||
Rated loading bucket capacity | m3 | 1 | |||
Rated Lifting Force | KN | 25 | |||
Engines rated power/rated speed | KW/r/min | 70/2200 | |||
Total operating weight | kg | 7400 | |||
Backhoe turning angle | Left | º | 90 | ||
Right | º | 90 | |||
Backhoe parameter | Max. digging radius | mm | 5150 | ||
Max. dump height | mm | 3738 | |||
Radius at the max. dump height | mm | 1084 | |||
Max. digging radius at ground level | mm | 5105 | |||
Digging buckets max. rotating angle | º | 180 | |||
Max. digging depth | mm | 4340 | |||
Max. digging force | KN | >50 | |||
Loading parameter | Max. dump height | mm | 2612 | ||
Dump reach at max. dump height | mm | 727 | |||
Bucket drawback angle | Transportation position | º | 43 | ||
Ground position | º | 34 | |||
Dump angle | º | 43.5 | |||
Digging depth | mm | 191 | |||
Max. breakout force | KN | >40 | |||
Max. grade ability | % | 16.7 | |||
Max. traction power | KN | 70 | |||
Gear and travel speed | Forward/Backward gear I | km/h | 5.9/5.9 | ||
Forward/Backward gear Ⅱ | 9.8/9.8 | ||||
Forward/Backward gear Ⅲ | 21.2/21.2 | ||||
Forward/Backward gear IV | 39.8/39.8 | ||||
Min. turning radius | mm | 3795 | |||
Total length | mm | 7077 | |||
Total height (Cab) | mm | 2700 | |||
Max. height for transportation | mm | 3424 | |||
Total Width | mm | 2350 | |||
Bucket width | mm | 2315 | |||
Loading Operation Parameter | |
Rated Bucket Capacity | 1.0m³ |
Max. Dumping Clearance | 2612 mm |
Max. Dump reach | 727 mm |
Dig depth | 191 mm |
Bucket upward angle at max. working height | 63° |
Drawback angle at ground pos. | 40° |
Max. breakout force | >40KN |
Rated Lifting Force | 25KN |
Rise Time | ≤5.5s |
Fall Time | ≤4.5s |
Tilting Time | ≤1.5s |
Excavating Operation Parameter | |
Rated Backhoe Bucket Capacity | 0.3 m³ |
Max. Digging Depth | 4340 mm |
Max. Digging Force | >50KN |
Max. Digging Radius | 5150 mm |
Max. Dump Height | 3738 mm |
Max. Outreach from mid. of Rear Axle | 6583 mm |
Max. Outreach at the max. dump height | 1084 mm |
Turning Angle | 180° |
