Color coated embossed aluminum coil with PE or PVDF

Mail applications of JINHU aluminium coated coil

1) Gas piping, cables, building materials, etc

2) Curtain wall decoration for buildings where security is important, such as airports, hospitals and research centers
3) Curtain wallboards for outside walls of normal buildings
4) Renovations of old buildings and movable houses
5) Reformation and decoration for indoor walls, ceilings, bathrooms,kitchens and balconies
6) Facades
7) Billboards, exhibition desks and notice boards
8) Wallboards and ceilings for tunnels
9) Materials for industrial application, car and ship bodies

Raw materials:

1,Aluminum alloy: AA1100, AA3003,or upon request

2,Surface coating:PE ,AC PVDF,DOUBLE PAINTING

Specifications:

 01) Alloy: A3003 A1100 A8011etc

02) Aluminum thickness: 0.018mm~1.20mm

03) Aluminum max width:1600mm

Standard width: 1200mm

Special width such as1200MM, 1300mm, 1520mm, 1570mm, 1595mm are also available

04) Coil's standard diameter: 1200mm

Interior diameter:150mm,405mm or 505mm

05) weight: 1.6T/coil ,2.6 T/coil

06) Coating finish:  PE,AC PVDF, DOUBLE PAINTING

07) Gloss: meet the customer requirement

08) Total coating thickness:

     PVDF coating: more than 25 micron

     Polyester coating: more than 18 micron

09) Coating hardness (pencil hardness) more than 2H

10) coating adhesive : no lower than first grade

11) Impact resistance: No cracking and peeling (50kg/cm ,ASTMD-2794:1993)

12) Flexibility (T-bend): 2T

13) MEK resistance: more than 100

14) Bottom side aluminum sheet is coated with protective polyester material, thickness more than 6 micron

15) outer packing ;export standard ,  wooden plate .

PE Coated Coil:

It can be classified matt and glossy according to the colors. The compact molecule structure assures paint surface luster and smooth, and assures good painting on the panel surface. With an warranty of 8-15 years for weather resistance, it is specially applied to internal decoration and sign abroad.

Colors

Our coated aluminum coil have so many color you can choose.for example,silver white aluminum coil,blue aluminum coil,red aluminum coil,etc.Colors from our Color Chart (we have 40 color samples), RAL, Pantone international color are available, also sending us your color samples are available.

If you have any question pls feel free to contract me,

susy  si:0086+15163933778

Whats app: +8615163933778

Packing& Delivery

Packing: in brown paper, and packing on the wooden pallet

Delivery: about 20days after deposite
