JS500 Concrete Mixer for Brick Production Line
- 100 Set / Sets per Month
- China Qingdao Port
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | HUALI | Model Number | JS500 | |
| Motor Power | 25.1kw | Mixing Power | 18.5kw | |
| Charging Capacity | 800L | Reclaiming capacity | 500L | |
| Speed of Mixing Drum | 25r/min | Water Supply Mode | auto | |
| Working Cycle Period | 2min | Discharge Way | Mechanical or electric operation | |
| Outline Dimension | 3030*2300*2680mm | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
JS500 Concrete Mixer for Brick Production line1.double axle concrete mixer
2.easy to maintain operate
3.high efficiency.
JS500 Concrete Mixer for Brick Production Line
(HUALI Brand )
Main technical parameters of JS500 | |
Rated discharging volume | 500L |
Rated feeding volume | 800L |
Rated productivity | ≥25m3/h |
RPM of mixing blade | 35r/min |
Number of mixing blades | 2×7 |
Model of mixing motor | Y180M-4 |
Power of mixing motor | 18.5KW |
Model of winch motor | YEZ132S-4 |
Power of winch motor | 5.5KW |
Model of water pump motor | 50DWB20-8A |
Power of water pump motor | 0.75kW |
Discharging height | 1500mm |
Discharging mode | JS500: manual; JS500D: electric; JS500Q: pneumatic; |
The maximum particle size of aggregate | 80/60(pebble / broken stone) mm |
External dimension (L*W*H) transportation state | 3030*2300*2680mm |
External dimension (L*W*H)Working state | 4480*3030*5280mm |
Weight of the whole machine | 4000kg |
Brief introduction of JS500
JS500 concrete mixer is applicable for mixing stiff concrete, pasty concrete, lightweight aggregate concrete and all mortars in all prefabricated structural parts factories and industrial & civil building engineering construction departments of water conservancy, road and bridge etc. It is used not only in independent operation and but also to combine into simple mixing plant with corresponding batching equipment.
According to different discharging modes, this machine includes manual type (JS500), electric type (JS500D) and pneumatic type (JS500Q). Features of the whole machine include reasonable structure, good mixing quality, short mixing time, low energy consumption and low noise etc. Main parts of electrical control system use import components with excellent performance and high reliability.
Standard discharging heights of this machine include: 1.5m, 2.7m and 3.8m (or design according to users’ requirements). Users can self-prepare tilting-carts and concrete mixing trucks that are matched with this machine.
