Product Details
| Condition | New | Usage | Other, walking tractor\irrigator\generator\air compressor,etc. | |
| Fuel | Diesel | Stroke | 4 Stroke | |
| Cylinder | Single Cylinder | Cold Style | Other, Water-cooled | |
| Start | Other, Motor Start or Hand Crank | Place of Origin | Jiangsu, China | |
| Brand Name | Huiyou | Model Number | ZS1105;ZS1105NL;ZS1105D;ZS1105ND | |
| Dimension(L*W*H) | 900 x 440 x 760mm | Weight | 178 kg |
Product Description
Specifications
18 hp diesel engineBig power,Low fuel consumption
Stabel performance
Reliable operation
Convenient maintenance,etc.
ZS1105 Diesel Engine
Water Cool, 1-Cylinder, 4-Stroke, Direct Injection
A. Main applications of the diesel engine:
As a power device used for walking tractor, irrigation and generating sets, air compressor, inland ships, engineering machinery, transportation vehicle and processing machines for agricultural products and sideline products.
B. Detailed description:
Model | ZS1105 | ZS1105NL | ZS1105D | ZS1105NLD | ZS1105WP |
Type | Single – cylinder, Horizontal, 4 –cycle | ||||
Combustion System | Direct Injection | ||||
Bore x Stroke (mm) | 105x115 | ||||
Displacement(L) | 0.996 | ||||
Compression Ratio | 17:1 | ||||
Output/Speed(hp/rpm) | 16/2200 | ||||
Max. Output (hp/rpm) | 18/2200 | ||||
Cooling System | Evaporative | Radiator | Evaporative | Radiator | Evaporative |
Lubrication System | Combined pressure and splash | ||||
Starting Method | Hand cranking | Starting motor | Hand cranking | ||
Gross Weight(kg) | 178 | 186 | 194 | 202 | 187 |
Packing Size(LXWXH)(mm) | 900x440x760 | ||||
20’ Container (set) | 96 | ||||
Remark | N-Radiator , D-Starting motor , L-Lamp , WP- Water circulation pump | ||||
