CRS-3200 Common Rail System Tester
You May Like
Product Description
Specifications
Test a common rail system, consists of a pump, a fuel rail and one injector of either solenoid or piezo technologies, plus 3 DRV
| CRS-3200 Common Rail System Tester |
| Test a common rail system, consists of a pump, a fuel rail and one injector of either solenoid or piezo technologies, plus 3 DRV valves on a conventional pump test bench. |
A standard high pressure pump test bench with a CR system tester CRS-3200 will fulfill most tasks for repairing a CR system and the components, such as to test an injector fuel injection and return quantities, nozzle spray atomization, and with the optional DRV valves to test pump condition by measuring the fuel flow at different rail pressures
Design Features
Simulate signals to drive a CR pump, one CR injector, plus 3 DRV valves
Pump control
Two independent channels of pump regulation valve control signals
The second channel is capable to drive 3 DRV valves (optional), to test pump capacity by measure the high pressure flow at different pump speeds and rail pressures.
Monitoring fuel rail pressure
Injector control
Dual drive outputs
Piezo injector made by Siemens
Solenoid injector
High voltage drive for Bosch/Denso injectors
Low voltage drive for Delphi injectors
Adjustable frequency and pulse width
Software based over-pressure protection
Short circuit protection for solenoid and piezo driving signals
Rich accessories, ready to test Bosch, Denso, Delphi and Siemens injectors and pumps
