shrinking packing machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1)Have CE and ISO9000 certificate
2)Shrink film:PE,POF,PV
3)The max packing speed:
15-30 packs/min (According bottle-type)

The packing machine main techincal standards

Name:	Automatic heat shrink packaging machine (Double-push bottle, heat sealing heat cutting)
Model:	DS-A400
The biggest suitable bottle-type:	H=335 Φ=120 (2×3 3×3 3×4)
The smallest suitable bottle-type:	H=120 Φ=55 (2×2 3×4 4×6)
The thickness of shrink film:	0.050.10mm (Can be designed as your special requirements)
Shrinkable bake temperature:	Can be arbitrary adjustable within room temperature~200
The max packing speed:	15-30 packs/min (According bottle-type)
Power supply:	380V/220V 50Hz three-phase five-line
Power:	About 26kW
Working air pressure:	0.6-0.8Mpa
Air consumption:	0.6m³/min
Conveyor level height, the position of enter material and dimension:	Design as the customers request
Shrink film:	PE, POF, PV etc.
Machine size:	L5850mm×W4000mm×H1900mm
Weight:	1100kg
