Home > Products > Water filling machine > RCCGF4-4-1 5l Water Filling Machine
RCCGF4-4-1 5l Water Filling Machine
- SHANGHAI PORT FOR 5l water filling machine
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Beverage, Other, Beverage, Machinery & Hardware | |
| Packaging Type | Case | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V/380V | Power | 1.5kw | |
| Place of Origin | Jiangsu, China | Brand Name | JINRI | |
| Model Number | RCCGF | Dimension(L*W*H) | 2200X2100X2200MM | |
| Weight | 2500kg | Certification | CE ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
RCCGF4-4-1 5l water filling machine
Description for 5l water filling machine
1. The filling station using all metal (not plastic) 304 stainless steel contact parts gives consistent accurate, high precision filling nozzle together with beverage buffer system, to ensure the high filling precision, ensure same filling level
2. All 304 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
3. No bottle no filling
4. Bypass line provided for flushing the product fill tank after completion of CIP, easy clean
technical parameter for 5l water filling machine
Model | RCCGF4-4-1 |
Working positions | Sterile water rinsing 4 Filling 4 Capping 1 |
Production capacity | 400bottles/hour (5L/bottle) |
Air pressure | 0.7MPa |
Air consumption | 0.8 m3/min |
Rinsing water pressure | 0.2~0.3MPa |
Rinsing water consumption | 2T/H |
Main motor power | 3Kw |
Total power | 3.37Kw |
Dimension | 3560X2760X2700 |
Equipment weight | 1900kg |
pictures for 5l water filling machine
washing filling capping machine
capping machine
