Heat Shrink Machine Tunnel

Heat Shrink Machine Tunnel

Technical data:

Type:TG-500A

 External size:L3700×W920×H1800mm

 Max.packing size:L600×W400×H350mm

 Shrinkage film:PE,PVC,POF

 Shrinkage film thickness:0.03-0.15mm

 Thermo shrinkage tunnel temperature: 160 - 260°can adjust at will.

 Max output per minute:0-10bags

 Facility power:18Kw

 Actual power:15Kw/h

 Voltage requirement:380/220V

 Facility weight:0.6T

 Fan:1.1Kw 3units 380V

Two,Facility basical configuration:

 Taiwan Telta frequency converter                  1set

 Stainless iron wing type heating tube                12 pieces

 China-America cooperation Teflon convey belt.

 Shanghai Hemei electric-motor and Zhejiang Taili worm speed transmission.

 Whole machine outter plastic-sprayed, the frame is made of high-quality carbon steel.

Three,Product descripition:

 Double-wind recyle fan machine, ensure the temperature in shrinkage tunnel evenly.

 Super wind-volume cooling system, ensure get into shape quickly.

 Anti-high temperature teflon convey belt, convey steadily, high-strength anti-abrasion.

 Frequency unlimited speed adjustment and belt convey structure.

 Wing type stainless iron heating system, endurance used.

Four,Technical condition and requirement:

 1, Packing method( Just for your reference):

(1) 350/500/550/600ML: large package:4×6,4×5 ; Small package: 3×4,3×5 four type of package method.

(2) 1L/1.5L/2L/2.5L: Large package:3×3,3×4; small package: 2×2,2×3 four type of package.

2,Regarding can package, we suggest adopt to package with tray , pack steadily.

3,Package speed:5-12bags/min

4,Package material:PE thermo shrinkage film width(200-600mm),thickness(0.08-0.12mm)

Picture Show
