Low rpm generator cheap brushless electric diesel generator by Shangchai engine
USD $12,500 - $13,500
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- Fuzhou
- T/T L/C D/P D/A Credit Card
You May Like
-
Brushless 100% copper powerful 200kw 250kva genset generator price list by shanghai engine
-
Global service low price open type electric start diesel generator cetificated by ISO9001
-
Chinese brand Shangchai cheap powerful genset 400kw 500kva CE approved 3 phase
-
Shangchai 50HZ 1500 low rpm generator diesel for sale water cooled with 6 cylinder
-
Open type ISO9001 approved 100kw 125kva diesel mini power plant for sale by Shanghai engine
-
China engine AC Three Phase Output Type diesel generator price ISO9001 approved
Product Details
| Place of Origin | Fujian, China | Brand Name | Shangchai | |
| Model Number | GF-250 | Output Type | AC Three Phase | |
| Speed | 1500rmp | Frequency | 50/60HZ | |
| Rated Power | 250kw/312.5kva | Rated Voltage | 400V/230V Adjustable | |
| Rated Current | 450A |
Product Description
Low rpm generator cheap brushless electric diesel generator by Shangchai engine
| Genset Information | |||
| Model | GF-250 | Net dimensions (mm) | 2800*1150*1680mm |
| Prime Output(kw/kva) | 250kw/312.5kva | Rated/Standby current(A) | 450A/495A |
| Gross weight (kg) | 3300kg | Net weight (kg) | 3300kg |
| Rated voltage(V) | 400V/230V | Noise (dB) | 100dB(A) |
| Fuel Comsuption (g/kwh) | 207g/kwh | Frequency (HZ) | 50HZ/60HZ |
| Steady voltage adjusting rate | ≤±1% | ||
| Transient voltage regulation | +20~--15 % | ||
| Voltage settling time | ≤1s | ||
| Steady State rate adjustment frequency | ≤±1% | ||
| Frequency fluctuation rate | ≤±0.5% | ||
| Transient frequency regulation | +10~-7% | ||
| Frequency recovery time | ≤3s | ||
| Generator configurations | |||
| Engine Brand: | Shangchai | Fuel Injection | Direct Injection |
| Engine Model: | SC13G420D2 | Bore (mm) | 135*150mm |
| Intake System | Turbo charging | Cylinder No. | 6/L |
| Cooling method | Closed circulating water cooling | Speed | 1500rpm |
| Compression Ratio | 16:01 | Governor | 110% |
| Starting mode | DC24V electrical starting | Speed adjustment mode | Electronic speed control |
| Alternator configurations | |||
| Alternator Brand: | Fengfengsheng | Protection Grade | IP22 |
| Alternartor Model: | TFW-250 | Connect method | Three phase four wire type y connection |
| Rated output (kw/kva) | 250kw/312.5kva | Excitation method | AVR(Automatic voltage regulator) |
| Rated voltage(V) | 400V/230V | Frequency (HZ) | 50HZ/60HZ |
| Insulation Grade | H Class | Power Factor | COS=0.8 |
