UCF201 / UCF202 / UCF203 / UCF205 / UCF206 / UCF207 / UCF208 / UCF209

Unit No.

Bearing No.

Housing No.

Shaft Dia

Boundary Dimensions(mm)

Bolt Size

Mass(Kg)

in.

mm

a

e

i

g

l

s

z

Bi

n

≈

UCF201-8

UC201-8

F204

1/2

86

63.5

15

11

25.4

12

33.3

31

12.7

3/8

0.7

UCF202-10

UC202-10

F204

5/8

86

63.5

15

11

25.4

12

33.3

31

12.7

3/8

0.7

UCF204

UC204

F204

20

86

63.5

15

11

25.4

12

33.3

31

12.7

M10

0.7

UCF204-12

UC204-12

F204

3/4

86

63.5

15

11

25.4

12

33.3

31

12.7

3/8

0.7

UCF205

UC205

F205

25

95

70

16

13

27

12

35.7

34

14.3

M10

0.8

UCF205-14

UC205-14

F205

7/8

95

70

16

13

27

12

35.7

34

14.3

3/8

0.8

UCF205-15

UC205-15

F205

15/16

95

70

16

13

27

12

35.7

34

14.3

3/8

0.8

UCF205-16

UC205-16

F205

1

95

70

16

13

27

12

35.7

34

14.3

3/8

0.8

UCF206

UC206

F206

30

108

83

18

13

31

12

40.2

38.1

15.9

M10

1

UCF206-17

UC206-17

F206

1-1/16

108

83

18

13

31

12

40.2

38.1

15.9

3/8

1

UCF206-18

UC206-18

F206

1-1/8

108

83

18

13

31

12

40.2

38.1

15.9

3/8

1

UCF206-19

UC206-19

F206

1-3/16

108

83

18

13

31

12

40.2

38.1

15.9

3/8

1

UCF206-20

UC206-20

F206

1-1/4

108

83

18

13

31

12

40.2

38.1

15.9

3/8

1

UCF207

UC207

F207

35

117

92

19

15

34

14

44.4

42.9

17.5

M12

1.4

UCF207-20

UC207-20

F207

1-1/4

117

92

19

15

34

14

44.4

42.9

17.5

7/16

1.4

UCF207-21

UC207-21

F207

1-5/16

117

92

19

15

34

14

44.4

42.9

17.5

7/16

1.4

UCF207-22

UC207-22

F207

1-3/8

117

92

19

15

34

14

44.4

42.9

17.5

7/16

1.4

UCF207-23

UC207-23

F207

1-7/16

117

92

19

15

34

14

44.4

42.9

17.5

7/16

1.4

UCF208

UC208

F208

40

130

102

21

15

36

16

51.2

49.2

19

M14

1.8

UCF208-24

UC208-24

F208

1-1/2

130

102

21

15

36

16

51.2

49.2

19

1/2

1.8

UCF208-25

UC208-25

F208

1-9/16

130

102

21

15

36

16

51.2

49.2

19

1/2

1.8

UCF209

UC209

F209

45

137

105

22

16

38

16

52.2

49.2

19

M14

2.2

UCF209-26

UC209-26

F209

1-5/8

137

105

22

16

38

16

52.2

49.2

19

1/2

2.2

UCF209-27

UC209-27

F209

1-11/16

137

105

22

16

38

16

52.2

49.2

19

1/2

2.2

UCF209-28

UC209-28

F209

1-3/4

137

105

22

16

38

16

52.2

49.2

19

1/2

2.2

UCF210

UC210

F210

50

143

111

22

16

40

16

54.6

51.6

19

M14

2.4

UCF210-30

UC210-30

F210

1-7/8

143

111

22

16

40

16

54.6

51.6

19

1/2

2.4

UCF210-31

UC210-31

F210

1-15/16

143

111

22

16

40

16

54.6

51.6

19

1/2

2.4

UCF210-32

UC210-32

F210

2

143

111

22

16

40

16

54.6

51.6

19

1/2

2.4

UCF211

UC211

F211

55

162

130

25

18

43

19

58.4

55.6

22.2

M16

3.6

UCF211-32

UC211-32

F211

2

162

130

25

18

43

19

58.4

55.6

22.2

5/8

3.6

UCF211-34

UC211-34

F211

2-1/8

162

130

25

18

43

19

58.4

55.6

22.2

5/8

3.6

UCF211-35

UC211-35

F211

2-3/16

162

130

25

18

43

19

58.4

55.6

22.2

5/8

3.6

UCF212

UC212

F212

60

175

143

29

18

48

19

68.7

65.1

25.4

M16

4.4

UCF212-36

UC212-36

F212

2-1/4

175

143

29

18

48

19

68.7

65.1

25.4

5/8

4.4

UCF212-38

UC212-38

F212

2-3/8

175

143

29

18

48

19

68.7

65.1

25.4

5/8

4.4

UCF212-39

UC212-39

F212

2-7/16

175

143

29

18

48

19

68.7

65.1

25.4

5/8

4.4

UCF213

UC213

F213

65

187

149

30

22

50

19

69.7

65.1

25.4

M16

5.5

UCF213-40

UC213-40

F213

2-1/2

187

149

30

22

50

19

69.7

65.1

25.4

5/8

5.5

UCF214

UC214

F214

70

193

152

31

22

54

19

75.4

74.6

30.2

M16

6.1

UCF214-43

UC214-43

F214

2-11/16

193

152

31

22

54

19

75.4

74.6

30.2

5/8

6.1

UCF214-44

UC214-44

F214

2-3/4

193

152

31

22

54

19

75.4

74.6

30.2

5/8

6.1

UCF215

UC215

F215

75

200

159

34

22

56

19

78.5

77.8

33.3

M16

6.9

UCF215-47

UC215-47

F215

2-15/16

200

159

34

22

56

19

78.5

77.8

33.3

5/8

6.9

UCF215-48

UC215-48

F215

3

200

159

34

22

56

19

78.5

77.8

33.3

5/8

6.9
