Adapter sleeve H3164 H3168 H3172 H3176 H3180
- Tianjin
- T/T Credit Card
You May Like
-
Adapter sleeve H3136 H3138 H3140 H3144 H3148 H3152 H3156 H3160
-
Adapter sleeve H3120 H3122 H3124 H3126 H3128 H3130 H3132 H3134
-
Adapter sleeve H3126
-
Adapter sleeve H2356 H2360 H2364
-
Adapter sleeve H2332 H2334 H2336 H2338 H2340 H2344 H2348 H2352
-
Adapter sleeve H2318 H2319 H2320 H2322 H2324 H2326 H2328 H2330
Product Details
| Place of Origin | Hebei, China | Brand Name | XTSEAO | |
| Model Number | H3168 | Type | Sleeve |
Product Description
1. Brand Name: XTSEAO & OEM
2. High precision, long life, low noise, high-end technology, low vibration and conform to the export standard
3.Package: Box packing, industrial standard packing, individual box packing or as customers' requirement
Specifications
Parameter of H31 Series Adapter Sleeve | |||||||
Model | Size(mm) | Model number of matched bearing | Weight(kg) | ||||
d | d1 | B1 | d2 | Self-aligning roller bearing | |||
H3122 | 110 | 100 | 81 | 145 | 23122K | 22222K | 2.10 |
H3124 | 120 | 110 | 88 | 155 | 23124K | 22224K | 2.50 |
H3126 | 130 | 115 | 92 | 165 | 23126K | 22226K | 3.45 |
H3128 | 140 | 125 | 97 | 180 | 23128K | 22228K | 4.10 |
H3130 | 150 | 135 | 111 | 195 | 23130K | 22230K | 5.25 |
H3132 | 160 | 140 | 119 | 210 | 23132K | 22232K | 7.25 |
H3134 | 170 | 150 | 122 | 220 | 23134K | 22234K | 8.10 |
H3136 | 180 | 160 | 131 | 230 | 23136K | 22236K | 9.15 |
H3138 | 190 | 170 | 141 | 240 | 23138K | 22238K | 10.5 |
Bearing Adapter Sleeve Model List
Adapter Sleeve | Withdrawal Sleeve | ||
H200 Series | H204-H222 | AH200 Series | AH208-AH256 |
H300 Series | H304-H322 | AH300 Series | AH308-AH334 |
H3000 Series | H3024-H3096 | AH2300 Series | AH2308-2356 |
H3100 Series | H3120-H3196 | AH3000 Series | AH3024-AH3096 |
H2300 Series | H2304-H2356 | AH3100 Series | AH3120-AH3196 |
H3200 Series | H3260-H3296 | AH3200 Series | AH3218-AH3296 |
Our company mainly produces Tapered Roller Bearing, Spherical Roller Bearing, Cylindrical Roller Bearing, Deep Groove Ball Bearing, Self-Aligning Ball Bearing, Angular Contact Ball Bearing, Thrust Ball Bearing, Spherical Roller Thrust Bearing, Pillow Block Bearing, Plummer Block & Adapter Sleeve, Needle Roller Bearing,Spherical Plain Bearing & Rod End, Agricultural Bearing, Linear Motion Ball Bearing, Self-Lubrication Bearing, Universal Joint,Automotive Hub Wheel Bearing, Automotive Hub Units, Automotive Clutch Release Bearing, Automotive Water Pump Bearing, Automotive Tensioner & Idler Bearing, Automotive Alternator Bearing, Automotive Air-Conditioner Bearing.
