Factory Supply Guide Rail Chain Cargo Lift
- QINGDAO
- T/T L/C D/P D/A
You May Like
-
China Hydraulic Vertical Cargo Lift Goods Lift Warehouse Guide Rail Lift
-
China Factory Price Special Discount 3.5m Cargo Stair Platform Lift for Sale
-
Vertical Chain Low Price Elevators Guide Rail for the Upper and Lower Floors
-
2015 Grade AAA Volkslift Guide Rails for Lift
-
2 Ton 3ton Construction Cargo Elevator Hydraulic Guide Rail Lift
-
2015 Unique Style Discount Stationary Cargo Lifter Price
Product Details
| Place of Origin | Shandong, China | Brand Name | TRUEWIN | |
| Model Number | SJE | Lift Mechanism | Lift Chain | |
| Lift Drive / Actuation | Hydraulic | Power | 1.1~3.0kw | |
| Rated Loading Capacity | 500-5000kg | Min. Lifting Height | 200mm | |
| Max. Lifting Height | as per your requirement | Table Size | as per your requirement | |
| Overall Dimensions | 1600x1300x1550mm | Weight | 300~1000kg | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
2015 Grade AAA volkslift guide rails for lift
Specification of volkslift guide rails for lift:
| Model | platform height (mm) | min lifting height (mm) | loading capacity (kg) | platform size (mm) | power (kw) |
| SJE0.3-3.5 | 3500 | 150 | 300 | 1000×800 | 1.5 |
| SJE0.5-4.5 | 4500 | 150 | 500 | 1500×1000 | 1.5 |
| SJE1.0-4.5 | 4500 | 150 | 1000 | 1500×1500 | 2.2 |
| SJE2.0-4.5 | 4500 | 150 | 2000 | 2000×1000 | 2.2 |
| SJE3.0-4.5 | 4500 | 160 | 3000 | 2000×1200 | 3 |
| SJE0.3-7.5 | 7500 | 150 | 300 | 1000×1000 | 1.5 |
| SJE0.5-7.5 | 7500 | 150 | 500 | 1200×1200 | 1.5 |
| SJE1.0-7.5 | 7500 | 150 | 1000 | 1800×1400 | 2.2 |
| SJE2.0-7.5 | 7500 | 150 | 2000 | 2000×1500 | 2.2 |
| SJE3.0-7.5 | 7500 | 160 | 3000 | 2000×1600 | 3 |
- Chain lifting platforms, with flexible lifting range, large loading capacity, are compact and light weight.
- Without restriction of space, they are widely used in lifting operations over large areas, such narrow space as warehouses, factories, highways and stairwell place where we could not dig pits.
- The platform moves smooth, operates simply, safely and reliably.
- The control button is all put on the ground panel, but they can be changed onto the platform or controlled by a remote controller.
- The power supply can be changed to Hydraulic driven power to meet the need where the electricity is not available.





3. One Year Quality warrant service, during the period spare part supplied free if you pay for shipping.
4.Professional team supply service for life long time.

A. Daily or refueling: Check the parts are good or bad Check hydraulic oil level and colour
B. Every 250hours or 3months: Change lubricating oil Check cylinders
C. Every 500hours or 6 months: Check tubes, pipes and value
D. Every 1000 hours or 1 year: Change hydraulic oil Grease rotation bearing and wear pads
E. Every 2000 hours or 2 years:Check hydraulic tank, lid and vent
F. Note: Maintain the chassis according to the Chassis’ Service manual
FAQ:
Q:Who are you? Trade Company or manufacturer?
A: We are manufacturer and we have our own trade company.
Q: When the product can be delivered?
A: Commonly the lead time will be within 15 days after payment.
Q:What’s the Min order to your company?
A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.
Q:What’s the advantage of your company?
A:We have exported our lifts and service to more than 100 countries. We have speclized team work for you, you will get our feedback within 24 hours./ Germany and Italian advancedmanufacturering technology.
Q:What need you know when i inquiry to you ?
A: We need to know your Max Capacity,Platform size and Lift height.
volkslift guide rails for lift
