CE&ISO9001:2000 Hydraulic Platform Lifts for Cargo Guide Hydraulic Lifting Platform
- QINGDAO
- T/T
You May Like
-
HOT 2.2kw Aerial Work Platform / Chain GUIDE Elevator
-
CE Warehouse Platform Ladder ,guide Hydraulic Lifting
-
Guide Hydraulic Lift Platform Warehouse Crane Loading Platform
-
Simple Maintenance Wall Mount Folding Platform /Guide Hydraulic Lifting Elevator
-
HIGH Transport Construction Material Telescopic Ladder /Guide Hydraulic Lifting Platform
-
Single Column and Double Column,the Four Pillars GUIDE Hydraulic Lifting Platform
Product Details
| Place of Origin | Shandong, China | Brand Name | TURE WIN, True win | |
| Model Number | SJG | Lift Mechanism | Lift Chain | |
| Lift Drive / Actuation | Hydraulic | Power | 2.2-5.0kw | |
| Rated Loading Capacity | 500-5000kg | Min. Lifting Height | 1m | |
| Max. Lifting Height | 15m | Table Size | 2500*1500 | |
| Overall Dimensions | 2700*1700*16500 | Weight | 1000kg | |
| Certification | CE&ISO9001:2000 | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description

Guide hydraulic lifting platform
Product Description
Guide hydraulic lifting platform elevator is a kind of shear fork hydraulic lift platform.Suitable for secondary and tertiary industrial workshop, restaurant, wine shop floor between the transport of goods.Minimum height in 150/300 mm, and need not the upper lifting point. Diversity of column (single, double, four pillars)Equipment running smoothly, the operation is simple and reliable, with hydraulic, electrical multiple protection, convenient transport of goods economy. Elevator guide rail type, widely used in industrial and mining enterprises instead of the elevator promotion goods, has the advantages of simple structure, large capacity, long service life, convenient maintenance, safe and practical characteristics, especially suitable for places with shaft can't dig underground foundation.
Model | Rated load (kg) | Raise distance (m) | Initial height (m) | Table size (m) | Power supply (v) | Motor power (kw) | Raise time (s) |
SJG-0.5T-2.5M | 500 | 2.5 | 0.5 | 2.2*1.5 | 380 | 1.5 | 37.5 |
SJG-1T-2.5M | 1000 | 2.5 | 0.6 | 2.2*1.5 | 380 | 2.2 | 37.5 |
SJG-0.5T-3M | 500 | 3 | 0.85 | 2.2*1.5 | 380 | 1.5 | 45 |
SJG-1T-3M | 1000 | 3 | 0.96 | 2.2*1.5 | 380 | 2.2 | 45 |
SJG-2T-3M | 2000 | 3 | 1.08 | 2.2*1.5 | 380 | 3 | 45 |
SJG-3T-3M | 3000 | 3 | 1.1 | 2.2*1.5 | 380 | 3 | 45 |
SJG-4T-3M | 4000 | 3 | 1.3 | 2.2*1.5 | 380 | 4 | 45 |
SJG-5T-3M | 5000 | 3 | 1.3 | 2.2*1.5 | 380 | 4 | 45 |
SJG-0.5T-4M | 500 | 4 | 0.85 | 2.2*1.5 | 380 | 1.5 | 60 |
SJG-1T-4M | 1000 | 4 | 0.96 | 2.2*1.5 | 380 | 3 | 60 |
SJG-2T-4M | 2000 | 4 | 1.08 | 2.2*1.5 | 380 | 3 | 60 |
SJG-3T-4M | 3000 | 4 | 1.1 | 2.2*1.5 | 380 | 4 | 60 |
SJG-4T-4M | 4000 | 4 | 1.3 | 2.2*1.5 | 380 | 5.5 | 60 |
SJG-5T-4M | 5000 | 4 | 1.3 | 2.2*1.5 | 380 | 5.5 | 60 |
SJG-5T-5M | 500 | 5 | 1 | 2.2*1.5 | 380 | 2.2 | 75 |
SJG-1T-5M | 1000 | 5 | 1.1 | 2.2*1.5 | 380 | 3 | 75 |
SJG-2T-5M | 2000 | 5 | 1.25 | 2.2*1.5 | 380 | 4 | 75 |
SJG-3T-5M | 3000 | 5 | 1.5 | 2.2*1.5 | 380 | 5.5 | 75 |
SJG-4T-5M | 4000 | 5 | 1.5 | 2.2*1.5 | 380 | 5.5 | 75 |
SJG-5T-5M | 5000 | 5 | 1.5 | 2.2*1.5 | 380 | 7.5 | 75 |
Function
A.Guide hydraulic lifting platform Maximum carrying 30 tons, implement multipoint control, interlocking fluctuation floor interaction, achieve safe use.High hoisting height, with set oil cylinders, or double oil cylinder, smooth operation, no noise, easy maintenance, long service life.Power down, emergency stop button manually, convenient, fast and practical.
B.Guide hydraulic lifting platform Pit depth is commonly 15 cm to 30 cm, unlimited top height, can be customized according to the environment Layer can be well versed in, door factory inside and outside can poke each other open, convenient, save a space; Especially suitable for 2-3 layers of steel structure workshop, internal and external all can use
C.Guide hydraulic lifting platform Pump station adopts imported pump station, if high speed requirements, USES the import custom pump station, to achieve the ideal delivery requirements, oil cylinder and sealers adopt imported components, resolve customer oil pressure is not stable, parts leak, optional electrical parts, (Shanghai people's electrical appliances, France schneider, Germany's Siemens)
Speciality
A.Guide hydraulic lifting platform Hydraulic elevator in a traditional traction type elevator safety devices at the same time, also has:flood valve When the system pressure is too high can prevent upward movement
B. Emergency manual valve:The power failure occurs, can make the capsules emergency position down to the nearest floor to open the door
C.Pipeline rupture valve:When the hydraulic system pipeline rupture capsules stall falls, can automatically cut off oil stopped falling
D.Tank of the oil temperature protection:When the medium oil tank temperature exceeds the set value, the oil temperature protection device of signal, suspended the use, when the oil temperature drop rear can activate the elevator.
E.manual pump:When a system failure occurs, the manual pump can be manipulated with high pressure oil capsules up to the nearest floor location
maintaining
Hydraulic elevator guide rail type when used in our daily life should pay attention to maintenance, prolong the life of it. Understand the mechanical equipment maintenance and maintenance problems:
1. The mechanism of the brake should regularly check and adjust the brake block and the clearance between the brake wheel, flexible and reliable. On the friction, there should be no dirt, in case of dirt must wash with gasoline or thinners.
2. The reducer, gearbox, the outer meshing gear and so on various parts of the lubrication and hydraulic oil are conducted in accordance with the requirements of lubrication in the table.
3.Check the connection of the ministries, such as loose should be tightened. The connecting bolts should be in body check elasticity while compression (can adopt the method of rotating arm to cause compression state), all connections slightly shaft must have a split pin, and need to open fully.
4.Regularly check whether the institutions functioning normally, there is no noise, such as troubleshooting, must be ruled out in time.
5.Have met motor overheating to stop in time, troubleshooting and then continue to run the motor bearing lubrication is good.
Our services
1.There was a problem at any time consulting, we 24 hours online
2. Our products are your exclusive, production of professional design
3. Quality assurance, you dare to buy I dare to compensate
If you have any interest in our products or any questions, please do not hesitate to contact me. I will help you to know more about our products' detail.
