7C SCREENED CABLE
- Shanghai & Ningbo
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JinJin | |
| Model Number | RG6 | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
Specifications
Product Feature:It has an excellent performance,reasonable price with excellent quality,material without pollution.7C SCREENED CABLE
Cable structure
RG-6 Electrical Characteristics
Capacitance | 50±3.0 nf/km | |
Impedance | 75±3.0 Ohms | |
Velocity of Propagation | 85% | |
Shielding Effectiveness | 55MHz | ≥60dB |
300MHz | ≥70dB | |
1000MHz | ≥70dB | |
Return Loss (100%swept) | 1-470MHz | ≥22dB |
470-1000MHz | ≥20dB | |
1000-2200MHz | ≥18dB | |
Attenuation Table(at 20°C)
For CATV | |
Frequency(MHz) | Maximum(dB/100m) |
5 | 1.9 |
55 | 5.25 |
83 | 6.4 |
187 | 9.35 |
211 | 10 |
250 | 10.28 |
300 | 11.64 |
350 | 12.63 |
400 | 13.61 |
450 | 14.43 |
500 | 15.09 |
550 | 16.08 |
600 | 16.73 |
750 | 18.54 |
865 | 20.01 |
1000 | 21.49 |
Application
It's widely used in CATV, MATV and CCTV equipments fields.
RAW MATERIAL:
ASSEMBLY LINE:
Brading:
SEMI-FINISHED PRODUCT
PACKAGE:
TESTING
RL TESTING, Characteristic Impedance, capacitance tsting,
PVC,FPE,MATERIAL DENSITY TESTING
EG: TESTING PAPER, We are very strict on quality control,from raw material to finished product,
Product Gallery:
Transportation
1). All available shipping ways could be applied, by courier,air or sea .
2). Appointed shipping company or our own forwarders all could be used in shipment .
3). Full -way tracking the cargos for you before the goods arrive .
For more information,welcome to meet me on Trade manager or just call us for free!
Thanks!
