2016 PIKES Sand Filter PS700B-1400 Side Mounted Type/domestic Fiberglass Swimming Pools and Spa Bathtub Sand Filter

S700B-1400 Swimming pool equipment/ side mount pool sand filter

1.Made of fiberglass

2.UV resistance surface

3.Emaux

1>.Features:

*Made of fiberglass

*Transparent lid cover allows easy inspection of the sand bed

*Top diffuser ensures even distribution of water over the top of the sand bed

*Top diffuser ensures even distribution of water over the top of the sand bed

*Air release valve enables easy release of trapped air during opertation of the filter

*Material s used are dependable,non corrosive and are suitable for all weather performance

*Large sand.water drain for rapid wintertime or servicing

*Easy to use water drain plug and multi-port valve lets you select any of the valves/filter operation with a simple lever-action

*Uv resistance surface allows the filer to work under direct sunlight

2>.Functions: Refer to 6- way Multi-port Valve

*  Maximum working pressure   250kPa/ 36psi/ 2.5bar

*  Factory testing pressure          400kPa/58psi/ 4.0bar

*  Size of silica sand                     0.5-0.8mm

*  Maximum filtration velocity       50m3/h/m2

*  Maximum water temperature  43 degree

3>.Technical Characteristics:

S450,   0.16 sq meter(filter area),   1.5’’/50mm(valve connections)   8.10 cbm/h(flow rate)   45kg(sand)

S500,   0.22sq meter(filter area),   1.5’’/50mm(valve connections)   11.1 cbm/h(flow rate)   85kg(sand)

S650,   0.32 sq meter(filter area),   1.5’’/50mm(valve connections)  15.6 cbm/h(flow rate)   145kg(sand)

S700,   0.40 sq meter(filter area),   1.5’’/50mm(valve connections)   19.5cbm/h(flow rate)  210kg(sand)

.................

S700(B),   0.41 sq meter(filter area),   2.0’’/63mm(valve connections)   20.16 cbm/h(flow rate)  215kg(sand)

S800,   0.53 sq meter(filter area),   2’’/63mm(valve connections)   26.1cbm/h(flow rate)  355kg(sand)

S900,   0.66 sq meter(filter area),   2’’/63mm(valve connections)   33.0 cbm/h(flow rate)  620kg(sand)

S1000,   0.82 sq meter(filter area),   2’’/63mm(valve connections)  40.2 cbm/h(flow rate)  620kg(sand)

S1200,  1.17 sq meter(filter area),   2’’/63mm(valve connections)   52.8 cbm/h(flow rate)  860kg(sand)

5>. Pictures
