Jerry Cans,bottles,jars Automatic Blowing Mold Machine/used Blow Molding Machine
- shanghai
- T/T
You May Like
-
Small Plastic Products Making Machine/used Hdpe Blow Molding Machine
-
Small Plastic Products Making Machine/bottles Blow Molding Machine
-
2L Blowing Molding Machine/bottle Blowing Machine
-
Full Automatic Small Plastic Bottle Blow Moulding Machine
-
Automatic Plastic Sea Ball Making Machine
-
Full Automactic Plastic Blow Molding Machine LDPE 200ml The Measuring Cup ABLB 45II
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | Other, LDPE,PE,PP, HDPE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | used blow molding machine | Model Number | used blow molding machine | |
| Voltage | 220V or 380V | Power(W) | 16.5kw | |
| Dimension(L*W*H) | 3.6*1.6*2.8m | Weight | 6.3ton | |
| Certification | CE, ISO | Warranty | 12months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
used blow molding machine1,CE Certification
2,Advanced technology
3,Good after-sale service
blow molding machine
Technical Parameters: ( ABLB45)
Max. Product volume | 2L |
Out put capacity | 500~600pcs/h |
Screw diameter | 45mm |
Screw L/D ratio | 24:1 L/D |
Screw drive power | 11 KW |
Screw heating capacity | 3 KW |
No.of heating zone | 3 zones |
Output of HDPE | 30 KG/H |
Oil pump drive power | 5.5 KW |
Clamping force | 35KN |
Max.size of mold | 250 X 320mm |
Mold stroke | 100-360mm |
Max.die diameter | 80mm |
Blowing pressure | 0.6 mpa |
Air Volume | 0.4M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 30 L/MIN |
Size of Machine | 2.6x1.4x2.2m |
Weight of machine | 2.8 ton |
