1000ml Detergent CE Approved Plastic Milk Bottle Molding Machine
- SHANGHAI
- T/T
You May Like
-
0~1L Blow Molding Machine for Making Bottles Balls
-
2L Blow Molding Machine for Making Bottles Balls
-
High Speed HDPE Bottles Balls Blow Molding Machine
-
10-30L Jerry Cans Automatic Blowing Mold Machine/extrusion Blow Molding Machine
-
Jerry Cans,bottles,jars Automatic Blowing Mold Machine/used Blow Molding Machine
-
Small Plastic Products Making Machine/used Hdpe Blow Molding Machine
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | plastic milk bottle | Model Number | plastic milk bottle | |
| Voltage | 220v or 380 0r 415v | Power(W) | 28kw | |
| Dimension(L*W*H) | 2.9*1.5*2.5m | Weight | 4.5ton | |
| Certification | CE, ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
plastic milk bottleenergy efficient ,cost saving, competitive price, high quality
plastic milk bottle
ABLB55 full automatic bottle making machine was specially designed for making plastic water bottles,medical bottles,lubricant oil bottles,cosmetic bottles, and other small plastic containers not over 3.5L. This design is low power consumption and very stable.
The features of this machine:
(1)It is suitable for producing PE,HDPE,PP, PVC,PETG,PS so on,plastic containers and bottles in all shapes are available,the duct volume is up to 3.5L.
(2)Single station single die head design,very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.
Technical Parameters: ( ABLB55 )
Max. Product volume | 3.5L |
Out put capacity | 400~600pcs/h |
Screw diameter | 55mm |
Screw L/D ratio | 24:1 L/D |
Screw drive power | 10 KW |
Screw heating capacity | 26 KW |
No.of heating zone | 3 zones |
Output of HDPE | 35 KG/H |
Oil pump drive power | 4.8 KW |
Clamping force | 32KN |
Max.size of mold | 320 X 360mm |
Mold stroke | 100—360mm |
Max.die diameter | 140mm |
Blowing pressure | 0.6mpa |
Air Volume | 0.5M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 40 L/MIN |
Size of Machine | 2.9x1.5x2.4m |
Weight of machine | 4.5 ton |
