Lockable Gas Spring (ISO9001:2008)
Negotiable
/ Piece
500 Pieces(Min. Order)
- SHANGHAI NINGBO
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Model Number | FYT-JKQ-26 | |
| Style | Cylinder | Load Type | Gas | |
| Material | Steel | Usage | Other, Medical equipment |
Product Description
Specifications
Lockable gas spring (ISO9001:2008)1.practical and economic
fessional design
3.durable and attactive
4.good quality
Lockable gas spring (ISO9001:2008)
1.Features:
1.the matieral is steel,and with nitrogen and little oil in tube.
2.surface: black or silver
nnector:ball joints or other types
4.excellent design
5. 50000 cycle guarantee,through(ISO9001)
petitive price
7.we can produce as your requirment.
2.usage:
It is widely applied in medical equipments,chairs and other product.The gas spring with some release mechanism can stop at the arbitrary position, then to make heavy locking force(can reach above 10000N).
3.Technical parameter
| Rod diameter [mm] | Tube diameter [mm] | Stroke [mm] | Extended lengh [mm] | Force rangeN |
6 | 15 | 20-250 | 2×stroke+60mm | 20-400N |
| 8 | 18 | 20-300 | 2×stroke+80mm | 50-800N |
| 10 | 22 | 20-400 | 2×stroke+85mm | 100-1500N |
| 12 | 22 | 20-400 | 2×stroke+85mm | 100-2000N |
| 12 | 28 | 20-500 | 2×stroke+90mm | 100-2500N |
4.Packing:each is paked in plastic bag,and 100 or 200 bags per CTN
5.Delivery: 20 days after receipt of payment
