Home > Products > PU Spray and Perfusion Equipment > Foaming Machine Processing Type Polyurethane Foaming Machine
Foaming Machine Processing Type Polyurethane Foaming Machine
- Dalian
You May Like
Product Details
| Condition | New | Product Type | Other, PU Foam Machine | |
| Place of Origin | Liaoning, China | Brand Name | Pro-F2008 | |
| Model Number | Pro-IIIB235 | Voltage | 220V | |
| Power(W) | 7000KW | Dimension(L*W*H) | 800x 700x1100(mm) | |
| Weight | 125KG, 125kg | Certification | CE | |
| Warranty | 18 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Foaming Machine Processing Type Polyurethane Foaming Machine
Accessories
Specifications
1.Max. Pipe length:90m(optional)
2.Power Source:380V 50/60Hz 3 Phases
3.Output:4~8kg/min
4.Transfer pump:2 sets
BHPU-F2008 Polyurethane Spray and Perfusion Equipment | |
Standard Configuration: | |
Mainframe: | 1 set |
Spray gun: | 1set |
Heating and preserved pipe: | 15m |
Connecting pipe for spray gun: | 1.5m |
Max. Pipe length: | 90m(optional) |
Transfer pump: | 2 sets |
Technical Parameter: | |
Power Source: | 380V 50/60Hz 3 Phases |
Air Source: | 0.5~0.8Mpa (70~120psi) ≥0.9m3 /min |
Output: | 4~8kg/min |
Heating device power for material: | 3000W X 2(or optional: 4500W X 2) |
Heating power for pipe heating: | 3500w |
Single component output pressure: | 5~10Mpa (700~1500psi) |
Heat temperature: | 80°C |
Shipping Parameter: | |
Weight: | 125kg |
Volume: | 800x 700x1100(mm) |
Features and Usage: | |
1. BHPU-F2008 Polyurethane Spray and Perfusion Equipment is as a special one, this type of machine gives you more choice because there are double spray guns with different Size. The function of Spray and Perfusions can be changed mutually, operating the machine more easily, because you should only change the spray gun. 2. Strong guidance, automatic reset device. After one day's work, through the operation can make the material pump reset to the next point, prolong the service life of the seal material. 3. BHPU-F2008 is widely used, such as Refrigerator heat preservation, Building exterior, Roof warm keeping and waterproof, Sports venues, Air-condition insulation, automobile and naval vessels, solar water heater, etc | |
Working
Project
Company information:
Q: Are You the factory or trade company?
A:We are the factory,found in 2000,
Q: Can you make the machine according to my demand?
A: Yes. we have professional team and development personnel can plan to the suitable designs you need.
Q:What's the MOQ?
A:One set, more should be discount.
Q:What's the type of payment?
A: 30% T/T in advance,70% T/T before shipment
Q:Why we choose you of all the same industry?
A:Our company have competitive quality and price in the whole industry,welcome to you visit any time.
Q: Do you have longlife after-sales service support?
A: Yes, our machine warranty period is 13 months, and support lifelong service.
B:We can offer 24 hours line service.
Contact Us
- Yingkou Professional Roll Forming Machine Co., Ltd.
- Contact nameYing Sun Chat Now
- Phone0086-0417-2937805
- AddressNo. 13 Bachang Lane Zhanqian District, Yingkou, Liaoning
