NEW Deviser AE200/AE220/AE260 Optical Power Meter
USD $1 - $2
/ Piece
1 Piece(Min.Order)
- 1000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card PayPal
You May Like
-
UNI-T UT396B New Professional Laser Distance Meters UT-396B 0.05-80m/120m
-
UNI-T UT396A Professional Digital Laser Distance Meters UT-396A 0.05-80m
-
600m LR600 Ranging telescope UNI-T laser range finder outdoor hunting tester
-
Laser Distance Meter AR881 Measurement Range 0.3-100m Laser Rangefinder Range Laser Range Finder
-
Ultrasonic Range Finder Smart Sensor AR851 Digital Ultrasonic Distance Meter Tester
-
60m Laser Distance Meters ut391A Digital Handheld Rangefinder High-precision Distance Measurements Tool
Product Details
| Place of Origin | Guangdong, China | Brand Name | Deviser | |
| Model Number | AE200 |
Product Description
Specifications
Optical Power Meter
Auto shutdown and self-calibration function
Built in VFL
> 50 hours working time
PC software supported
Deviser AE200/AE220/AE260 Optical Power Meter
Overview
AE Series OPM is an ideal testing instrument for fiber network installation, debugging and maintenance in optical network, CATV and FTTX field. It is a handset with high accuracy, low power consumption and easy to carry. It also supports vision optical source and automatic wavelength and frequency identification.
Key Features
- Up to 50 hours working time with 3 5AA rechargeable batteries
- Auto shutdown and self-calibration function
- USB Interface and toolbox software
- VFL
Specifications
AE200A AE220 AE260 | |||
Accuracy | ±0.23 dB (±5%) | ±0.17 dB(±3%) | |
Optical Detector | InGaAs | InGaAs Φ2000 μm | InGaAs |
Dynamic Range | -43 dBm ~ +25 dBm | -70 dBm ~ +6 dBm | |
Linearity | 0.07 dB / 10 dB | ||
Resolution | 0.01 dBm, mW, μW, nW | ||
Wavelength | 850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm, 1610nm, | ||
650nm VFL | Power 1 mW(3, 5, 10 mW optional) | ||
Connector | FCSCST adjustable | ||
Operating Temperature | -10 °C ~ +60 °C | ||
Work Time | >70 Hours (backlight off) | ||
Dimension | 185 mm × 85 mm × 45 mm | ||
Weight | 320 g (excluding battery) | ||
