Coating Thickness Meter CM-8829 (F/NF/FN type)
- T/T Credit Card PayPal
You May Like
-
digital thickness meter CM10FH
-
digital thickness meter CM10F
-
coating thickness meter tester gauge CM10F
-
TASI-675 Digital Coating Thickness Gauge Painting Width Detectable Substrate Material Ferrous metal as iron, steel
-
Film/Coating Thickness Gauge GM280 Paint thickness meter
-
Film/Coating Thickness Gauge GM220 Paint thickness meter
Product Details
| Place of Origin | Guangdong, China | Brand Name | Graigar | |
| Model Number | CM-8829 |
Product Description
Specifications
thickness meter, thickness tester, ultrasonic thickness gauge,coating thickness gauge, CM-8829Coating Thickness Meter CM-8829 (F/NF/FN type)
Coating thickness meter is widely used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.In industries of petroleum,shipbuilding,power station,and machine manufacturing.
With separate probe (please specify probe type, in built or separate while ordering)
Operating principle:
CM-8829F: F type(magnetic induction), measure the thickness of non-magnetic coating layers such as (aluminum,chrome,copper,ename1,rubber,paint) on magnetic substrate (steel, iron, alloy and magnetic steel)
CM-8829NF: NF type (eddy current), measure the thickness of non-conductive coating layers (ename1, rubber, paint, vanish, plastic anodic oxide layer) covered on non-ferrous substrate (aluminum, brass, zinc, tin and non-magnetic stainless steel)
CM-8829FN: F type & NF typeSpecifications:
In built probes
Measuring range: 0-1250um/0-50mil
Resolution: 0.1/1
Accuracy: ±1-3%n or ±2.5um
Min. measuring area: 6mm
Min. sample thickness: 0.3mm
Battery indicator: low battery indicator
Metric/ imperial: convertible
Power supply: 4x1.5V AAA(UM-4)battery
Auto power off
Operating conditions: 0-+45C(32F-104F), ≤90%RH
Dimensions: 126x65x27mm (5x2.6x1.07 inch)
Weight: 115g / 0.25lb (not including battery)
Optional accessories: other range 0-200um to 15000um
