Home > Products > NDT Instruments > KCT100 elcometer paint coating thickness gauge
KCT100 elcometer paint coating thickness gauge
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
TASI 676 Digital Coating Thickness Gauge Painting Width 0 to 40mils Hi or Lo Storage 255 datas Ferrous and non-Ferrous
-
BSIDE CCT01 Coating Thickness Gauge
-
CM8801N Digital Coating Thickness Gauges
-
Digital LCD car Coating Thickness Gauge Car Painting Thickness Tester Paint Thickness Meter DIY Instrument EM2271 0-80mil 0.1MM
-
Nicety CM8801FN Coating Thickness Gauge Meter Tester 0-1250um/0-50mil
-
Film/Coating Thickness Gauge GM280F Paint thickness meter
Product Details
| Place of Origin | Guangdong, China | Brand Name | Graigar | |
| Model Number | KCT100 |
Product Description
KCT100 elcometer paint coating thickness gauge
,Power-on
Keystroke once;Wait until READY! is displayed on the LCD. Now the gauge is ready for measurements.
2,Zeroing
Keystroke twice; when BASE ZERO is displayed, place flat on surface; hold steady. After measurement is obtained, DONE is shown and gauge beeps. Then lift gauge.
Note: Please conduct zeroing process after changing base. Zeroing process could be repeated for better results.
3,Two-Point User Calibration
Keystroke three times, enter into the process of tow-point user calibration; when
USER CAL BASE is shown on the LCD, please conduct a measurement on the base first; when
S1 is shown on the LCD, place Shim S1 on the base, conduct a measurement on shim S1 and lift gauge; when
S2 is shown on the LCD, place Shim S2 on the base, conduct a measurement on shim S2 and lift gauge; When DONE is displayed, it is ready for use.
Note: The two-point user calibration process could be repeated for better results.
4,Unit Change
Keystroke four times, convert from ums to mils or vice versa.
5,Reset
Keystroke five times, gauge resets.
