Electric vertical test stand AEV-5000/10000/20000/30000 Double Column Machine
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Screw Test Stand ALX-B Screw Tensile Testing Machine with steel ruler
-
Digital force guage SF-500 (2N-500N)
-
ADT Horizontal Torsion Spring Tester Torsion Guage Test Stand
-
AEH series Electric Horizontal Test Stand
-
HF-50K Digital Force Gauge with External Sensor Push Pull Tester Meter 50KN/50000N Load
-
Digital torque gauge ANL-20 torque meter
Product Details
| Place of Origin | Guangdong, China | Brand Name | Graigar or OEM | |
| Model Number | AEV | Power | Electronic |
Product Description
Electric vertical test stand AEV-5000/10000/20000/30000 Double Column Machine
AEV Electric Vertical Machine is a push pull load test stand specially equipped for HF series and NK series
force gauges.This product adopts dual vertical pole structure, featured by good stability, wide application and
easy to use, etc., with the functions of stepless speed regulation, manual (crawl) and automatic switching. This
product is appropriate for the push&pull load, plug power and other destructive tests in the industries of rubber,
plastics, light textile, building doors and windows, composite materials, wire and cable, auto parts, power
machinery and research institutions, etc.
Features:
1.Electric loading, stepless speed regulation, gear drive
2.Compact structure and stable drive
3.Simple operation, can be used with a variety of fixtures
Specifications and Parameters:
1.Maximum load:5000-30000N
2.Effective stroke:220 /1000mm
3.Test speed:15~240 mm/min
4.Working voltage:110-220V
5.Length × width × height(mm):400x250x1050 (Increasing the height of type is 1300)
6.Net weight:56(Increasing the height of type is 58)Kg-120kg
| Item No. | Effective stroke | Max. load | Testing speed | G.W. (kg) |
| AEV-5KN | 220mm | 5000N | 15—240mm/min | 75kg |
| AEV-10KN | Not fixed | 10000N | 90kg | |
| AEV-20KN | 20000N | |||
| AEV-30KN | 30000N |
