Digital Fruit Hardness Tester Fruit Sclerometer GY-4 Durometer and Test Stand GYD

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Graigar
Model Number	GY-4

Digital Fruit Hardness Tester Fruit Sclerometer GY-4 Durometer

Brief description:

1. Can store 896 peaks of data .The LED show the peaks of data, and get ride of the data .

2. Can output data; analyze the data by connected with computer.

3. With digital peak value holding function, hold the peak value for 2 seconds and the peak value will be automatically cancelled.

4. Green environmental-protective: If you do not operate the machine after 10 seconds, the machine will be shut down automatically.

Technical parameters:

Model	GY-4
Measurement Range	0.2 - 15 Kg/cm² (×10⁵ Pa )	0.4 - 30 Kg/cm² (×10⁵ Pa )
Division value	0.01 Kg/cm²	0.01 Kg/cm²
Pressure head diameter	1^# ¢11.1mm	2^# ¢7.9mm
Precision	±1%
Indication error	±0.5%
Unit	Kg/cm²(×10⁵ Pa)
Data interface	RS232 nine-hole socket
Display mode	Digital
Sensor structure	Tye sensor with high precision (inner sensor)
Insertion depth of pressure head	10mm
Ambient temperature	5°c~35°c
Ransport temperature	-10°c~60°c
Relative humidity	15%~80%RH
Net weight	450g
Outline dimension	2306636mm
