Digital Soil Hardness Tester TYD-2 hardness meter

Digital Soil Hardness Tester TYD-2 hardness meter

Characteristic:

1High accuracy and high resolution: large screen LCD display, with backlight function (backlight for night use), inverted reverse function of numbers on the screen

2. Battery capacity display: divide into 3, 2 and 1 grids. If battery capacity is too low, the instrument will shut down automatically

3. Gravity acceleration setting function: users can input the exact value of gravity acceleration of testing site to make the test more precise

4. Peak value maintaining function: maintain the peak value display until zero adjustment manually

5. Automatic peak function: maintain displaying the peak values for 2S before automatic elimination

6. Large memory storage function: can store 896 measuring values.

7, Data output function, data can be imported to the computer for various analysis

8, Auto-off time setting: 10min-90 min automatic shutdown can be set.

9, High quality charging power:100-240v of charging voltage can be available

Technical Parameter

1,   Model, TYD-2.

2,   Maximum load: 100Kg (Kg and N can be switched automatically).

3,   Resolution: 0.01Kg.

4,   Accuracy: ±0.5%.

5,   Measuring depth: 0~450mm.

6,   Power, charging power supply: 220V/AC, Continuous operating time of battery,6~8 hours

7,   Stability, temperature drift: 0.2u^V/°C(0-60°C),Null drift,≤ 0.1%/8 hours /FS

8,   Calibration range: full-scale calibration.

9,   Ambient temperature: 0~ 60°C.

10, Ambient humidity: ≤ 80%.

11, Allowable overload: 150%.

12, Power supply mode: 5 nickel cyanogens battery /220V AC charge 4~6hour.
