Home > Products > Pin type insulators for high voltage > Porcelain Insulator
Porcelain Insulator
- Shanghai;Shenzhen
- T/T D/P D/A
You May Like
Product Details
| Place of Origin | Jiangxi, China | Brand Name | TSBXJ | |
| Model Number | 55series insulator | Type | Insulator | |
| Material | Other, porcelain, porcelain | Application | High Voltage | |
| Rated Voltage | kn | Tensile Strength | kv |
Product Description
INSULATOR
Cat.No. | 55-1 | 55-2 | 55-3 | 55-4 | 55-5 |
Creepage Distance mm | 102 | 127 | 178 | 229 | 305 |
Dry Arcing Distance mm | 57 | 86 | 114 | 127 | 159 |
Cantilecer Strength KN | 13 | 11 | 11 | 13 | 13 |
Low Frequency Dry Flashover Voltage kv | 35 | 45 | 56 | 6 | 80 |
Low Frequency Wet Flashover Voltage kv | 30 | 35 | 50 | 50 | 50 |
Positive kv | 100 | 115 | 125 | 125 | 125 |
Negative kv | 100 | 115 | 130 | 130 | 130 |
Maximum RIV at 1000kHz uv | 50 | 50 | 50 | 50 | 50 |
Test Voltage to ground kv | 7.5 | 7.5 | 10 | 10 | 10 |
Power-frequency Puncture Voltage kv | 44 | 67 | 67 | 67 | 111 |
Net Weight Each APPROX kg | 5 | 5.5 | 5.5 | 6 | 7 |
Number in Standard Package | 27 | 44 | 44 | 44 | 67 |
