Drilling Desander

FOB Price

US$ 2,000 - 5,000 / Set

1 Set(Min. Order)

Port any port of china
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	zhongshi
Model Number	all

Product Description

Specifications

1. API Desander
2. Made from high-resistant material. 10", 12" Hydrocyclones are available

Desander
ZQJ Desanding cleaners is used to remove out the smaller solid-phase particles. Compared to the past one ,this device has been improved by 30% -50% in desanding efficiency, resulting in a reliable guarantee of the drilling speed increased and the drilling costs saved. It also can play the role of cleaner of sand and mud in the deep well.

Structural characteristics:
the composition with the base and support, a damping spring, hydrocyclones, the vibrating screen and so on. Thereinto ,the hydrocyclone has the polyurethane lining and the aluminum alloy shell ,and the aperture of the below outlet is adjustable according to different requirements .

Technical parameters:

Name	Parameters
nominal diameter of hydrocyclone (mm )	300
The number of hydrocyclone (pcs)	2
Handling capacity ( m³ / h )	100-200
Critical particle size ( μm )	50-150
Working Pressure ( Mpa )	0.2-0.4
Excitation rotating speed ( r / min )	1400
Screen area ( mm² )	1240 × 585
Electric power of motor ( kw )	1.1
Shape size ( mm )	1400 × 1030 × 1700
Total weight ( kg )	750
