Aluminium-Plastic Blister Packing Machine

Specifications

It adopts a cycloid pin gear device for the main driving unit,
which has long life and smooth running.

This machine was developed on the basis of our current market research, which is
a test product specially designed for the small-scale pharmaceutical factory, department of pharmaceutical of hospital and research institute of pharmaceutical factory. It adopts a cycloid pin gear device for the main driving unit, which has long life and smooth running. It has a coordinated process for shaping, feeding and heat, which has long life and smooth running. It enjoys the advantages such as accurate synchronization, clear cross-hatching, adjustable stroke and easy mould replacement. It is suitable for the combined sealing packing for capsules, table, food, chemical industrial products and electronic components. Main transmission is adopted with imported gear reducer with long life and lower noise. Adjustable stroke, plate dimensions can be changed freely, suitable for multiple kinds of specifications.

It can pack products of any shape such as flat plate structure, ellipse, square
and triangle.

Specifications:

1) Production ability: 20,000 ~ 50,000 tablets/h
2) Punching frequency: 30 times/min
3) Standard edition: 57 x 80mm
4) Power: 220V, 50Hz, 2.6kw
5) PVC: 0.2 ~ 0.25 x 65 ~ 70mm (width)
6) Aluminum foil of PTP: 0.02 x 65 ~ 70mm (width)
7) Overall dimension: 880 x 480 x 980mm
8) Weight: 180kg
