FEWR Electric Wheelchair Ramp With Anti-skip Platform for Bus
- shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | XINDER | |
| Model Number | FEWR-1 |
Product Description
INTRODUCTION:
- FEWR folding electric wheelchair ramp cab be applied for low-floor city bus. It is installed on vehicle floor.
- This ramp is developed at the basis of FMWR electric wheelchair ramp. And this ramp has the same working principle and installation position with FMWR folding manual wheelchair ramp. However, FEWR wheelchair ramp mainly use gear motor to complete the entire work process.
- When the vehicle breaks, the driver controls the operating switch to unfold the ramp, so that the wheelchair can get into/out of vehicle easily. Then after the wheelchair get into/out of vehicle, the driver control the operating switch to stow the ramp.
- There are many advantages of FEWR folding electric wheelchair ramp, such as low height, easy installation, easy operation, taking no space of vehicle and so on.
- The operation of wheelchair ramp is easy, simple, independent and wholly safety. This ramp takes no space of vehicle. Moreover, the platform of ramp and the floor of vehicle are at the same level, so there is no effect for passengers.
Technical Features:
- Driving Mode: Electric
- Deadweight: 45Kg
- Max Loading Capacity: 350Kg
- Material: Aluminum Board
- Test: 100000 time
Model | Driving Mode | Dimension (L*W*H) | Platform Size | Loading Capacity | Own Weight |
FEWR-1 | Electric 12V or 24V | 858*952*149mm (With base) | 850*920mm | 350 KG | 52KG |
FEWR-2 | Electric 12V or 24V | 902*952*149mm (With base) | 880*920mm | 350 KG | 52KG |
Dimensions
We can develop ramp especially according to customers’ requirements. Customers can inform us the specification of the vehicle, and we will some adjustments in order to ensure the ramp is suitable for the vehicle. Please refer to the following figures.
Model | Platform Net Size | Base Width | Overall Height | Base Length | Overall Length | Remark |
FEWR-1 | 850*920 | 932 mm | 149 mm | 848mm | 872 mm |
|
FEWR-2 | 880*920 | 932 mm | 149 mm | 878mm | 902 mm | Standard size |
