KG910B Kaishan Rotary Drilling Rig Borehole Drilling Machine
- ShangHai or NingBo
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Condition | New | Type | Rotary Drilling Rig | |
| Power Type | Diesel | Brand Name | KaiShan | |
| Model Number | KG910B | Usage | Ore | |
| Voltage | 220/380V | Power(W) | 33 | |
| Dimension(L*W*H) | 4100x2030x2020 | Weight | 3100 | |
| Certification | ISO9001 | Warranty | 1 Year | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
Welcome to SHAANXI KAISHAN EQUIPMENT CO.,LTD.
Best quality goods, lowest price, perfect service.
Cooperation terms:
1.Price: FOB any port in china.
2. Minimum order: 1set.
3. Payment: T/T, L/C, O/A ect.
4. Shipping: 20-30 days.
KG910B Crawler Rotary Portable Drilling Rig machine:
KG910B is one type machine improved from KY100 . It works in open air. On KY100 base, KG910B is
optimizing and upgrading the hydraumatic system , the part of drill boom and part walking and so on . It
has better function more than KY100 , for example : more motor , stronger gradeability ,more reasonable
drilling angle , faster rotation and propulsion speed and so on . Life of its motor is longer. It's more
reliable than its old version.
KG910B Crawler Mining Bore Hole Drilling Rig specification:
Rock rigidity | F=6-20 |
Diameter of hole | Φ80-105mm |
Optium drilling depth | 25m |
Rotation speed | 120r/min |
Rotation torque | 980N.m |
Lift power | 15 KN |
Feed way | oil cylinder-chain |
Feed distance | 2000mm |
Walk speed | 0-2.0 km/h |
gradeability | 30° |
Ground clearance | 254mm |
Weight | 3300kg |
Size of drill rig | 4100*2030*2020mm |
Sliding carriage pitch angle | Blow 118.5°,elevation23.5, total 142° |
Sliding carriage swing angle | Left36.5°,righ11.5,total 48° |
Drill boom pitch angle | 35°-60° |
Sliding carriage suppling length | 900mm |
power | YC2108(33KW 2200r/min) |
Drill pipe | Φ60 |
Working air pressure | 0.7-1.0Mpa |
Air consumption | 9-13 m³/min |
comment | steam liquid linkage |
KG910B Drilling Rig Comparing with KY100 Drilling Rig:
KG910B | KY100 | remark | |
Power | YC2108 | YC2100 | |
Walking parts | Horsepower+reducer | Steel horsepower | Reduce horsepower pressure, improve its life |
Walking pressure | 11Mpa | 14-16 Mpa | |
Rotation horsepower | Cycloid horsepower | Steel ball horsepower | Improve horsepower |
Rotation speed | 105r/min(diesel1700r/min) 120r/min(diesel2200r/min | 70r/min(1700) | Rotation speed improve 50% |
Hydraulic system | 25pump,fast rotation and lift valve , new flow divider and connect | 16 pump | Increase the flow |
Feeding speed | 390mm/s | 280mm/s | Improve 40% |
The matching KaiShan Air compressor: LGCY10/10
Mode | Capacity | Working Pressure | Diesel Engine | Dimension |
LGCY-10/10 | 10 | 1 | 4BTA3.9-C125 | 3900×1920×1900 |
We will provide package in accordance with your request and the products will be delivered after 20-30 days.
The products provided by us is of 1 year warranty, and on-line service will be supplied by us in time whenever you have any problem or question about the products you want to purchase or have purchased from us.
Our Company:
1. Shanxi Kaishan Mechanical & Electrical Equipment Co., Ltd. is located in a
Beautiful ancient City - Xi'an. Since founded more than 10 years ago, our
company has accumulated much experience in the business of air compressors
and drilling rig machines
2. National Free-inspection Product,Have passed ISO9001 certification.
3. Good Service, competitive price, high quality, fast shipping and perfect after
sale service.
Welcome to visit our factory and would like to start the cooperation with you in the near future.
