HVT-2601T CCTV PTZ Controller Camera Tester UTP Cable TDR 12V 1A Video Recorder

Model

                                  HVT CCTV TESTER

HVT-2601T  ( 6th generation)

Video Test

Signal mode

NTSC/PAL (Auto adapt)

Display

3.5 inch digital TFT-LCD ,480(RGB)x 320 resolution

LCD adjustment

Brightness, Contrast, Saturation adjustable

Video IN/OUT

1 channel BNC Input & 1 channel Output

Video Output Mode

1.0 Vp-p

Video Level test

Level test

Video signals measured in IRE or mV

PTZ controller

Communication

Support RS232 and RS485

PTZ Protocol

Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.

Baud Rate

600,1200,2400,4800,9600,19200,57600,115200bps

Video Signal Generation

Color bar generator

Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color )

UTP CABLE TEST

UTP cable test

Test UTP cable connection status and display in the screen. Read the number of the test box.

DC12V 1A power output

DC12V power output

 Output DC12V1A power for camera

Audio input test

Audio input test

test the pickup and other audio equipments on the front-end

RS485 data analysis

Data Monitor

Captures and analyzes the command data from controlling device

10 x zoom of image

Image 10x zoom

10x zoom image display and video out

Photograph,Video record, Record playback

Photograph

snapshot and save the current image as JPG file

Video record

Video record and storage the file

Record playback

To view the storage file in the SD card

Port flicker

Port flicker

Find the connected POE port quickly.

IP scan, Link monitor, PING test

IP scan

Find out the connected IP camera or the other network equipment IP address quickly.

Link monitor

Check the IP address whether is occupied

PING testing

Test IP camera or Ethernet port of the other network equipment whether work normally, and check the IP address

POE tester

POE tester

Display the power supply voltage and cable connection states

TDR Tester

 Only for T model

TDR Tester

breakpoint and short circuit measurement(BNC cable, telephone cable)

POWER

Power Adapter

DC 5V(1.5A)

Battery

Built-in 3.7V Lithium polymer battery ,3000mAh

Rechargeable

After charging 3-4 hour, working time lasts 11 hours

Low Consumption

Energy saving technology, the battery icon real-time display

Parameter

Operation setting

English/Chinese and other languages OSD menu

Auto off

5-60 (mins)

Keytone

On/Off

General

Working Temperature

-10°C---+50°C

Working Humidity

30%-90%

Dimension /Weight

194mm x 112mm x 48mm / 540g
