Extruded polystyrene rigid foam insualtion blue wall panel
- 50000 Piece / Pieces per Month
- SHANGHAI or NINGBO
You May Like
-
Fire resistant extruded polystyrene foam paddle thinner board 6mm-50mm
-
Floor Heating Systems Type Heating Film XPS Tile Backer Board
-
XPS roof tiling bathtub cement coated board
-
Extruded polystyrene foam tile substrate panel
-
XPS styrofoam Jagged bathtub cladding panel wedi extrusions
-
Styrofoam U/L pipe casing/pipe boxing
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Olingen | |
| Model Number | XPS shower floor board |
Product Description
Product name | Extruded polystyrene rigid foam insualtion blue wall panel |
Composition | XPS core,Alkali Mesh,Polymer Mortar Layer |
Quality | Grade A |
MOQ(SQM) | 100pcs |
Application | Wash Room |
Loading port | Shanghai Port |
Payment terms | T/T 30% deposit, balance to be paid before shipment |
Delivery time | 25-30 days after receiving 30% deposit |
Characteristics | Eco-saving,Lightweight,moisture-proof,easy construction,acid resistance. |
Quality sample | Offer free sample on your courier account(DHL.UPS.TNT.FEDEX.ECT) |
Usage | wet areas , wash room,ect. |
Standard dimensions and weight
Thickness(mm) | Weight(kg/m²) | Length by width(mm*mm) |
6 | 2,7 | 1220 x 600 |
10 | 2,9 | 1220 x 600 |
12 | 3,0 | 2440 x 600 |
20 | 3.1 | 2440 x 600 |
30 | 3,3 | 2440 x 600 |
50 | 4,2 | 2440 x 600 |
Technical Properties
Property | Rating |
Density | 36kg/m3 |
Thermal conductivity | <=0.035w/(m*k) |
Compressive strength(10%deflection) | Minimum of 0.25N/m m2
|
Flexural strength | 2.05N |
Water absorption(2-day immersion) | <=1% |
Water absorption(capillary) | 0 |
Coefficient of linear expansion | 30*10-6 |
Water vapour permeability | 0.028ng/pa.m.s |
EU controlled substance content | None |
Applications
Sample: offer free sample on clients' courier account. samples are available within 3-5 working days
Mass production delivery: Normally one container order needs 25-30 days .
MOQ: accept wholesale and retail , if quality is more than a container , we can give u discount .
Quality guarantee : 15-20 years quality guarantee .
Customised:we can produce the products for customised accroding to customer demand.
Zhejiang Olingen Building Material Systems Co.,Ltd Specialized in production,design,sales and installation of building materials for 20 years.Its main production include:artificial stone/ brick ;gravel,EPS components,XPS cement products.
