XPS rigid panels with both sides mortar board

FOB Price

USD $4 - $20 / Piece

200 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Olingen
Model Number	XPS shower floor board

Product name	XPS waterproof shower floor board
Composition	XPS core,Alkali Mesh,Polymer Mortar Layer
Quality	Grade A
MOQ(PCS)	100PCS
Application	Exterior Wall or Interior Wall
Loading port	Shanghai Port or Ningbo
Payment terms	T/T 30% deposit, balance to be paid before shipment
Delivery time	25-30 days after receiving 30% deposit
Characteristics	Eco-saving,Lightweight,moisture-proof,easy construction,acid resistance.
Quality sample	Offer free sample on your courier account(DHL.UPS.TNT.FEDEX.ECT)
Usage	wet areas , wash room,ect.

Standard dimensions and weight

* Dimensional tolerances for standard boards: Thickness +/- 1.5mm, Width+/- 2mm, Length +/- 2mm

Technical Properties

Property	Assessed to	Rating
Xps Density	DIN 53420	36 ± 0.02 kg/m3
Thermal Conductivity	EN 12167	0.033 W/m.K
Compressive Strength (10% deflection)	EN 826	300 kPa (30 tonnes/m2)
Flexural Strength	ASTM C203	0.30 ± 0.02 MPa
Water Absorption (2-day immersion)	ISO2896	0.2% by volume
Water Absorption (Capillary)	DIN 53428	Zero
Water Vapour Diffusion Resistivity (µ)	DIN 52615	110 - 225 µ
Water Vapour Permeability	ASTM E-96	0.028 ng/Pa.m.s
Maximum Tile Loading Weight	CERAM121107	60kg/m2
Flammability	EN 13501	Class E
Impact Sound Reduction	BS-ISO140-	dLw = 21
EU controlled substances conten	N/A	none

Features

Applications:Underfloor heat insulation board

Our Services

Sample: offer free sample on clients' courier account. samples are available within 3-5 working days

Mass production delivery: Normally one container order needs 25-30 days .

MOQ: accept wholesale and retail , if quality is more than a container , we can give u discount .

Quality guarantee : 15-20 years quality guarantee .

Customised:we can produce the products for customised accroding to customer demand.
