EMMCHINA WE67K-400/6000 CNC Bending Press Brake Machine Iron Sheet Press Brake
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
EMMCHINA WE67K-125/3200 Hydraulic Press Brake Bending Machine Price
-
EMM WE67K-160/3200 CNC Hydraulic Sheet Metal Bending Machine Press Brake Price
-
EMM Series WC67Y 160/5000 E200 Hydraulic Plate Press Brake Bending Machine
-
EMM WE67K-200/3200 DA56 Cnc Hydraulic Press Brake Bending Machine With Foot Pedals
-
EMM WC67K 80/4000 E21 nc Hydraulic Press Brake Bending Machine With Foot Pedals
-
EMM WE67K-250/3200 DA52 Small Cnc Hydraulic Press Brake Machine for Sales
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | EMM | Model Number | WE67K-400/6000 | |
| Machine Type | Press Brake | Raw Material | Other, plate | |
| Material / Metal Processed | Carbon Steel | Power | Hydraulic | |
| Automation | Automatic | Extra Services | Other, bending | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
EMMCHINA WE67K-400/6000 CNC bending press brake machine iron sheet press brake
This cnc hydraulic press brake for sale is high-efficiency and high-precision in bending sheet metal. Using different kinds of upper and lower dies can bend all kinds of work pieces. One slider travel makes a sheet bending and the complicated shape work piece may be achieved through bending many times.
cnc hydraulic press brake for sale overall structure
a ) Using UG (finite element) analysis, through computer aid design, with nice appearance.
b ) The machine structure is welded with steel plate, with sufficient strength and rigidity. The hydraulic drive prevents the machine from serious overload operation accidents caused by the change of sheet thickness or bad choice of lower die cavity. Additionally, this machine is also featured by the steadiness of work, convenience of operation, and reliable safety.
c) The mechanic block is equipped in the oil cylinder to ensure the fixing accuracy when the slider travels to the bottom dead point and so as to assure the consistency of bending angle in bulking production.
d )Using German technology to eliminate internal stress.
e ) Entire frame using striking grit to get rid of rust and spout anticorrosive paint.
| Model | Nominal force(KN) | Worktable length mm | Poles distance mm | Throat depth mm | Slider travel mm | Open max mm | Power KW | Dimension mm |
| 40/1600 | 400 | 1600 | 1305 | 200 | 110 | 300 | 4 | 1800x1100x1870 |
| 40/2000 | 400 | 2000 | 1650 | 200 | 110 | 300 | 5.5 | 2200x1100x1870 |
| 40/2500 | 400 | 2500 | 2050 | 200 | 110 | 300 | 5.5 | 2700x1100x1870 |
| 40/3200 | 400 | 3200 | 2600 | 200 | 110 | 300 | 5.5 | 3400x1100x1870 |
| 50/3200 | 500 | 3200 | 2600 | 250 | 120 | 315 | 5.5 | 3400x1200x2150 |
| 63/1600 | 630 | 1600 | 1300 | 250 | 120 | 350 | 5.5 | 1800x1300x2250 |
| 63/2500 | 630 | 2500 | 2050 | 250 | 120 | 350 | 5.5 | 2700x1300x2250 |
| 63/3200 | 630 | 3200 | 2600 | 250 | 120 | 350 | 5.5 | 3400x1300x2250 |
| 80/2000 | 800 | 2000 | 1650 | 250 | 120 | 360 | 7.5 | 2200x1300x2260 |
| 80/2500 | 800 | 2500 | 2050 | 250 | 120 | 360 | 7.5 | 2700x1300x2260 |
| 80/3200 | 800 | 3200 | 2600 | 250 | 120 | 360 | 7.5 | 3400x1300x2260 |
| 80/4000 | 800 | 4000 | 3200 | 250 | 120 | 360 | 7.5 | 4200x1300x2410 |
| 100/2500 | 1000 | 2500 | 2050 | 320 | 120 | 380 | 7.5 | 2700x1350x2350 |
| 100/3200 | 1000 | 3200 | 2600 | 320 | 120 | 380 | 7.5 | 3400x1350x2450 |
| 100/4000 | 1000 | 4000 | 3200 | 320 | 120 | 380 | 7.5 | 4200x1350x2500 |
| 125/2500 | 1250 | 2500 | 2050 | 320 | 120 | 380 | 7.5 | 2700x1350x2350 |
| 125/3200 | 1250 | 3200 | 2600 | 320 | 120 | 380 | 7.5 | 3400x1350x2450 |
| 125/4000 | 1250 | 4000 | 3200 | 320 | 120 | 380 | 7.5 | 4200x1350x2500 |
| 160/2500 | 1600 | 2500 | 2050 | 320 | 155 | 420 | 11 | 2700x1510x2595 |
| 160/3200 | 1600 | 3200 | 2600 | 320 | 155 | 420 | 11 | 3400x1510x2595 |
| 160/4000 | 1600 | 4000 | 3200 | 320 | 155 | 420 | 11 | 4200x1510x2695 |
| 160/6000 | 1600 | 6000 | 4800 | 320 | 155 | 420 | 11 | 6200x1710x2880 |
| 200/2500 | 2000 | 2500 | 2050 | 320 | 200 | 440 | 15 | 2700x1680x2675 |
| 200/3200 | 2000 | 3200 | 2600 | 320 | 200 | 440 | 15 | 3400x1680x2675 |
| 200/4000 | 2000 | 4000 | 3200 | 320 | 200 | 440 | 15 | 4200x1680x2725 |
| 200/6000 | 2000 | 6000 | 4800 | 320 | 200 | 440 | 18.5 | 6200x1680x3345 |
| 250/2500 | 2500 | 2500 | 1900 | 320 | 250 | 520 | 18.5 | 2700x1690x2825 |
| 250/3200 | 2500 | 3200 | 2600 | 320 | 250 | 520 | 18.5 | 3400x1690x2875 |
| 250/4000 | 2500 | 4000 | 3200 | 320 | 250 | 520 | 18.5 | 4200x1690x2960 |
| 250/6000 | 2500 | 6000 | 4800 | 320 | 250 | 520 | 18.5 | 6200x1690x3100 |
| 300/3200 | 3000 | 3200 | 2600 | 400 | 250 | 535 | 22 | 3400x2020x3150 |
| 300/4000 | 3000 | 4000 | 3200 | 400 | 250 | 535 | 22 | 4200x2020x3125 |
| 300/6000 | 3000 | 6000 | 4800 | 400 | 250 | 535 | 22 | 6300x2050x3610 |
| 350/3200 | 3500 | 3200 | 2600 | 400 | 250 | 540 | 22 | 3500x2040x3100 |
| 350/4000 | 3500 | 4000 | 3200 | 400 | 250 | 540 | 22 | 4300x2040x3160 |
| 350/6000 | 3500 | 6000 | 4800 | 400 | 250 | 540 | 22 | 6300x2040x3500 |
| 400/4000 | 4000 | 4000 | 3200 | 400 | 320 | 615 | 30 | 4300x2100x3160 |
| 400/6000 | 4000 | 6000 | 4700 | 500 | 320 | 615 | 30 | 6300x2420x3500 |
| 500/4000 | 5000 | 4000 | 3200 | 400 | 320 | 635 | 30 | 4300x2240x3510 |
| 500/6000 | 5000 | 6000 | 4800 | 400 | 320 | 635 | 30 | 6300x2240x3615 |
EMMCHINA WE67K-400/6000 CNC bending press brake machine iron sheet press brake
2. As the electromagnetic force is applied, the compression plate is capable of processing various kinds of workpieces and workpieces with side wall.
3. This machine is classified into 3 types, i.e. the manual type, NC type and the CNC type
4. Estun E21, E200 NC control system, Delem DA52, DA65 CNC Press Brake Control system
5. Electric components are from SIEMENS
6. Hydraulic system: Omega
7. The CNC system we adopt based on the synchronization mode, including the torque-axle synchronous type, machine-hydraulic synchronous type and the electro-hydraulic synchronous type.
8. The press is made of the steel via welding, and has sufficient strength and rigidity
9. It adopts the hydraulic upper transmission, and the cylinders at two ends of the machine are mounted onto the slider to directly drive the sliding movement.
10.The torque-axle synchronous mechanism is applied to the slider.
11.The mechanical stop block works stably and reliably
12. The slide stroke is maneuverable for rapid adjustment and manually operable for fine adjustment with counter display.
13. The inclined wedge-type deflection compensation mechanism is utilized for ensuring high bending accuracy.
14. More than twenty years’ experience of machine tools. Overseas service and technology support
Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week
1. Reply within 24 hours
2. Provide relevant product information
3. Answer question of customer's requirement
4. Give technical suggestion
Provide After-sales service 24hr × 7days per week
1. Test the machine before shipment
2. Provide technical guidance relate to use the machine
3. Supply one-year warranty period for the machine
4. Provide the spare parts at cost price after warranty period
5. Collect the feedback for the machine working
6. Provide long-term technical assistance.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EMMCHINA WE67K-400/6000 CNC bending press brake machine iron sheet press brake
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EMMCHINA WE67K-400/6000 CNC bending press brake machine iron sheet press brake
