Q55Y-165 metal ironworker

FOB Price

USD $500 - $76,567,673 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Pneumatic	Place of Origin	Jiangsu, China
Brand Name	EMM	Model Number	Q55Y-165
Voltage	380V	Power(W)	15KW
Weight	5075 KG	Dimension(LWH)	2700x1120x2160mm
Certification	ISO9001	Warranty	1 YEAR
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Q55Y-165 metal ironworker
1. punching machine
2. ironworker machin
3. ironworker

Q55Y-165 metal ironworker
Features:

The EMM model of hydraulic punching machines all come equipped with a deep throat of 600mm as standard.

Heavyduty support tables with scales and backstops, universal die holder for punching in plate, flat bar, angle iron and flange of channel and beam are all part of the standard execution.

The EMM hydraulic punching machines are available from 60 ton to 200 ton. Furthermore, tooling from competitor’s machines and or other brand-names can be used without special machine-modifications.

Technical Capacities and Specifications

Q55Y-165 metal ironworker

Model	Unit	Q55Y-165
Punching Pressure Ton	Ton	165 Ton
Max. capacity	mm	40x32
Diameter x thickness	mm	57x18
Stroke length	mm	80
Standard throat depth punch	mm	600x600
Largest hole(standard equipment)	mm	57
Largest hole(optional equipment)	mm	160
Maximum section	mm	380
Working height	mm	1075
Corner notch(optional equipment)	mm	-
Maximum capacity	mm	250sq x 6
Tube notch(optional equipment)		-
Maximum outside diameter	mm	165
Bending(optional equipment)	mm	-
Bar bend. max. capacity	mm	250x25
Sheet bend. max. capacity	mm	700x4
Technical data	mm	-
Motor power	kw	15kw
Net weight-punch	mm	5075
Machine dim.(Lx W x H)	mm	2700x1120x2160
