Xlb-d Rubber Vulcanizing Equipment With Ce Iso9001 New Price
- Qingdao Port
- T/T
You May Like
-
Xlb-400 * 400 Rubber Seals Vulcanizing Machine Molding Equipment
-
Rubber Vulcanizing Press Machine/Rubber Vulcanizer / Rubber Vulcanizing machine
-
200T hydraulic rubber plate vulcanizing machine
-
rubber conveyor belt vulcanizing machine
-
Rubber brick making machine/ rubber brick vulcanizing press machine
-
Big Style Making Rubber Conveyor belt Vulcanizing Machine
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | JINRUNQI | Model Number | XLB 2000X2000 1200X1200 | |
| Voltage | 380V | Power(W) | 17-66kw | |
| Dimension(L*W*H) | 4800x6500x4500 | Weight | 140000 | |
| Certification | ISO CE | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Qingdao Jinrunqi Rubber Machinery
Rubber Vulcanizing Equipment
Structural features:
- Large plate vulcanizing press is adopt frame structures,the platen and plunger are all made of superior material,they are accuracy processed and have high wear-resistance.
- Electrical system adopts PLC control, convenient and correct.Controlled by PLC, several programs could to be process through automatic control, to check and adjust the heating temperature with automatic, improving control level, labor strength and product efficiency.
- This large plate vulcanizing press is used to produce textile construction coneyor belt, such as ordinary rubber conveyor belt, nylon conveyor belt, PVG belt, steel wire core conveyor belt etc.
- The machine is mainly used for vulcanizing and processing large rubber components, rubber products and large width rubber conveyor belt.
Rubber Vulcanizing Equipment Rubber Vulcanizing Equipment
Rubber Vulcanizing Equipment technical Parameters
Type | 1500×2000 | 1800×1800 | 2000×2000 | 3000×3000 | 3100x4200 |
Norminal Mould Clamping Force(MN) | 12.00 | 20.00 | 20.00 | 31.50 | 48.00 |
Plate size (mm) | 1500×2000 | 1800×1800 | 2000×2000 | 3000×3000 | 3100x4200 |
Daylight of plate (mm) | 300 | 300 | 300 | 800 | 250 |
Working layer number | 2 | 2 | 2 | 1 | 1 |
| Diameter of piston | 500 | 500 | 600 | 600 | 600 |
| Stroke of piston | 600 | 600 | 600 | 800 | 250 |
| Unit area pressure of hot palte | 4.0 | 6.17 | 5.0 | 3.5 | 3.7 |
| Main motor power | 17.5 | 20.5 | 22 | 61 | 66 |
| Number of cylinder | 4 | 4 | 4 | 6 | 12 |
| Overall size ( L x W x H ) | 2000x2500x4040 | 2500x2300x4100 | 2500x2500x4180 | 4500x4820x4200 | 4800x6500x4500 |
| Weight | 30000 | 35000 | 42000 | 85000 | 140000 |
| Speed of closing (mm/s) | ≥6 | ≥6 | ≥6 | ≥5 | ≥4 |
| Speed of opening (mm/s) | ≥4 | ≥4 | ≥4 | ≥3 | ≥3 |
Also we can make non-standard rubber machinery as customer’s requirements.
Rubber product
It is used to make conveyor belt,rubber sheets,rubber mat,rubber tile,rubber O-rings,rubber gasket,solid tyre,moulded rubber products etc
1. Pre-sales Service:
Freely provide project designing, Professional suggestions, Quicky Response!
2. Medium-sales Service:
Accompany you to complete the purchasing, shipping, installing and training
3. After-sales service:
one year quality guarantee, Life-long Maintenance, Eneineer is avaliable to go overseas install and train your workers.
Rubber Vulcanizing Equipment Rubber Vulcanizing Equipment
If you interested in our products mentioned above. Kindly welcome to our factory for a visit and let us know by return email.
