electric diesel engine
- 100 Set / Sets per Month
- Fuzhou Port
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | China | |
| Model Number | SMC, Saint Meilan | Output Type | AC Three Phase | |
| Speed | 1500RPM/1800RPM | Frequency | 50/60HZ | |
| Rated Power | 11KW-1000KW | Rated Voltage | 110V/240V, 220V/380V, 230V/400V, 240V/415V | |
| Rated Current | 20-2000A |
Product Description
Specifications
diesel engine1 Lowest price, superb quality
2 Noise 70 db (7 meters away)
3 CE, ISO
4 12 months warranty
diesel engine
Genset Model | SMQ-8 | SMQ-10 | SMQ-12 | SMQ-15 | SMQ-20 | SMQ-24 | SMQ-30 | |
Rated Power (kw) | 8 | 10 | 12 | 15 | 20 | 24 | 30 | |
GENERATOR | Type | Brush or Brushless Alternator | ||||||
Frequency H z | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
Cont.A C output (Kw) | 7.5 | 9 | 11 | 13 | 17 | 23 | 27 | |
Power Factor | 1 for one phase and 0.8 for three phase | |||||||
Exictation System | Self-excitation & Brushless or Brush | |||||||
ENGINE | Model | QC380 | QC385 | QC480 | QC485 | QC490 | QC498 | QC4102 |
Number of cylinders | 3 | 3 | 4 | 4 | 4 | 4 | 4 | |
Cont.output (Kw) | 10 | 11 | 14 | 17 | 22 | 27 | 33 | |
Starting system | 12V or 24V Electric Starting | |||||||
Cooling method | Closed/Open circle water-cooied | |||||||
Firing order | 1-3-2 | 1-3-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | 1-3-4-2 | |
Compression Ratio | 22.5 | 22 | 18 | 18 | 18 | 19 | 19 | |
Specific fuel consumption (g/kW .h) | ≤265 | ≤262 | ≤249 | ≤245 | ≤243 | ≤258 | ≤258 | |
Steady speed regulation ≤5% | ||||||||
Instantaneous speed regulation ≤10% | ||||||||
Time required to steady Speed(s) ≤5 | ||||||||
Fluctation rate of speed ±0.5% | ||||||||
DIMENSIONS | Fuel tank capacity (L) 100 | |||||||
Overall dimensions (L×W×H)(mm) | 1650*900*1000 | 1650*900*1000 | 1800*900*1000 | 1800*900*1000 | 1800*900*1000 | 1800*900*1000 | 1800*900*1000 | |
| Dry weight (kg) | 640 | 670 | 680 | 730 | 810 | 1130 | 1180 |
Soundproof/Silent Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6. 1m<80 dB / 7m<70dB
PMC System:
1. Standard 23 pitch windings avoid excessive neutral current
2. Permanent magnet generator system provides constant excitation under all condition
3. Optional accessories available for easy paralleling with mains or other generators
4. AVR auto voltage regulation, auto exciter, auto adjustment
Accessories:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer
Our Advantages:
1. Solve your technical problems in 24 hours and provide international warranty service for engines.
2. Design the appearance form according to customers request.
3. Polyester varnish for appearance protecting for shining and raining.
4. Two hours testing before out factory.
5. ISO9001 and CE.
6.We enjoy Gold supplier in at least two years.
