Best Selling 12/20kV copper conductor 3x240mm2 Armored Power Cable

Best Selling 12/20kV copper conductor 3x240mm2 Armored Power Cable

Product details:

Name: 12/20kV, Cu/XLPE/STA/PVC 3*240mm2

Conductor shape: Compression Circular

Standard: IEC 60502-1997

Or equivalent DIN, BS, AS/NZS, JIS, ASTM, IS, etc.

Package: Steel or wooden Drum

Additional Options: Halogen free, flame retardant, Low smoke, Anti-termite.

Technical details:

Conductor: Conductor cross section of 800mm2 or below is stranded through compacting round core, with better roundness and higher compacting coefficient. Conductor cross section more than 800mm2 is made by segment of Milliken method to minimize skin connecting and alternating current impedance and increase power transmission capacity of cable.

Insulation: XLPE.

Product line: CCV

Metallic screen/sheath: Copper wire and tape

Armor: Steel tape/wire

Outer sheath: PVC, MDPE, HDPE, LDPE

Characteristic of use:

1. Allowable max. long-time operation temperature of cable conductor: 90°C
2. Allowable Max. short circuit temperature of cable conductor (max. sustaining period not exceeding 5s): 250 °C
3. Allowable Min. bending radius when laying cable, generally 20 times of the cable diameter

Main Cross sections for 26/35kV Power Cable:

Single core or three cores: 50mm², 70mm², 95 mm², 120 mm², 150 mm², 185 mm², 240 mm², 300 mm², 400 mm²

Quality and service:

Our motto: “Reputation based, Quality prioritized”, we wins customers trust for following reasons:

1, Quality control strictly follows ISO9001:2008 and ISO14001:2004, while guarantee that all products we supplied are totally new and unused. They are made of best material by first-class process techniques while tested and qualified by all specified testing items.

2, The Company promises to offer high-quality after-sale service to our customers. The service for cable fixation, installation and testing are available at customer request, if necessary technicians are sent to give instructions to the customers. After make sure it is the problem on quality we will repair or replace the defected products, the concerned expense or loss will be at our side.

3, The Company guarantees to deliver products in compliance with the bidding documentation.

4, The Company promises to offer cooperation and service according to the binding contract and requirements of supervision, testing for products.

1. Uo/U: 450/750V, 0.6/1KV, 1.8/3KV, 3.6/6KV, 6/10KV, 8.7/15KV, 12/20KV, 18/30KV, 21/35KV, 26/35KV

2. Standard applied: IEC, GB, BS, VDE, AS/NZS, UL or as per requirement

3. Working temperature: 70~125 °C

4. Conductor: solid or stranded pure annealed copper or aluminum

5. Insulation: XLPE or PVC or PE or LSZH

6. Cores: 1~5 cores, 3+1 cores, 3+2 cores, 4+1 cores for low voltage, 1 core or 3 cores for MV power cable

7. Cross section area: 1.0~630 sqmm for single core, 1.0~300 sqmm for multicores

8. Armoure: armore type is optional, SWA (steel wire armored) or STA (steel tape armored) for multicores, AWA (aluminum wire armored) or ATA (aluminum tape armored) for single core

9. Sheath: PVC or PE or Low smoking and halogen free compounding, etc.

10. Color: black or as per requirement

11. Flame retardant or Fire resistance or Low smoking and halogen free or other properties can be available

12. Wooden drum package or as per request

13. Certificates: ISO9001, ISO14001, OHSMS18001, CE, CB, CCC, SAA, etc

14. OEM can be available

15. Taifa cables have very good sales over the world, enjoying a very good reputation based on top quality and most competitive price and 5-star service.
