All Aluminum Conductor AAC 100mm 125mm

FOB Price

US$ 1 - 9,999 / Kilometer

50 Kilometers(Min. Order)

Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	taifa
Model Number	AAC	Type	Bare
Application	Overhead	Conductor Material	Aluminum
Conductor Type	Solid	Insulation Material	Other, bare

Product Description

Specifications

All Aluminum Conductor (AAC)
1.AAC Standard: ASTM B231, IEC61089, BS215 part1, DIN48201 part5, BS EN50182
2.CE, ISO9001, 14

All Aluminum Conductor AAC 100mm 125mm

All Aluminum Conductor (AAC),ACSR(Aluminum Conductor Steel Reinforced) is widely used in the overhead power distribution system of our country.

We can supply this conductor according to different recognized standards,such as IEC61089,BS215,ASTM B232,CSA C49,DIN48204,JIS C3110, customer special specification also can be satisfied.

The data sheets below show part spec of IEC61089

Code Number	Stranding&Wire Diameter		Approx Overall Diameter	Sectional Area			ApproxWeight	Breaking Load	DC Resistance
	Al	Steel	Approx Overall Diameter	Al	Steel	Total	ApproxWeight	Breaking Load	DC Resistance
	mm	mm	mm	mm²	mm²	mm²	Kg/km	KN	Ohm/km
16	6/1.84	1/1.84	5.53	16	2.67	18.7	64.6	6.08	1.7934
25	6/2.30	1/2.30	6.91	25	4.17	29.2	100.9	9.13	1.1478
100	6/4.61	1/4.61	13.80	100	16.70	117.0	403.8	34.33	0.2869
125	18/2.97	1/2.97	14.90	125	6.94	132.0	397.9	29.17	0.2304
160	18/3.36	1/3.36	16.80	160	8.89	169.0	509.3	36.18	0.1800
250	22/3.80	7/2.11	21.60	250	24.60	275.0	880.6	68.72	0.1154
400	54/3.07	7/3.07	27.60	400	51.90	452.0	1510.3	123.04	0.0723
450	54/3.26	7/3.26	29.30	450	58.30	508.0	1699.1	138.42	0.0643
500	54/3.43	7/3.43	30.90	500	64.80	565.0	1887.9	153.80	0.0578
560	54/3.63	19/2.18	32.70	560	70.90	631.0	2103.4	172.59	0.0516
630	54/3.85	19/2.31	34.70	630	79.80	710.0	2366.3	191.77	0.0459
710	54/4.09	19/2.45	36.80	710	89.90	800.0	2666.8	216.12	0.0407
800	72/3.76	7/2.51	37.60	800	34.60	835.0	2480.2	167.41	0.0361
900	72/3.99	7/2.66	39.90	900	39.90	939.0	2790.2	188.33	0.0321
