HYM Full automatic QT8-15 hydraulic concrete hollow brick and block making machine
- 20 Set / Sets per Month
- xiamen
- T/T
You May Like
-
Full automatic QT Concrete brick machine production line QT5-15 paving brick forming machine
-
Buy cheap hollow bricks making machine from Huayuan Machinery--- QT6-15 cement concrete brick machines
-
2013 HYM Full automatic brick building machine QT4-15 concrete building bricks making machine south africa
-
Automatic Pallet Loading Machine for block making plant
-
PVC Pallet, for block making machine
-
Low price hot sales QT4-15 block machine for making paver for sale
Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 20sets per month | Place of Origin | Fujian, China | |
| Brand Name | HYM concrete block making machine | Model Number | QT8-15 used concrete block making machine | |
| Voltage | 220V/380V | Power | 38.1KW | |
| Dimension(L*W*H) | 9800*3600*2800MM | Certification | ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.simens PLC controller2.anti-wear, aseismatic,anti Moist welding
3.high temperature carburizing heat treatment mold
HYM Full automatic QT8-15 hydraulic concrete hollow brick and block making machine
Main Features
1. Machine frame: adopt high strength steel and special welding technology manufacturing, very strong. 2.Realization of full automatic block production, saves the operation time, provide the production efficiency. 3. Mould head: mechanical and electrical hydraulic synchronous drive, the same height error rarely plate products, good product consistency. 4. Broken arch type cloth device (particularly favorable to porous brick cloth, the more homogeneous) 5. Configuration material feeding device, two fabric to produce various color face or perfect floor tiles. 6. multi-purpose of the machine. change the mold to produce various specifications of hollow block, multi-holes brick, paver brick and planting grass brick, slope protection brick, etc. 7. Control system has the self-locking function, to avoid the misoperation. Can implement remote fault diagnosis through telephone calls, real-time safeguard customer production run smoothly. Production raw materials: the stone powder, sand, gravel, cement, can be a lot of adding fly ash, slag, steel slag, coal gangue, ceramsite, perlite and other industrial waste Multiple uses, it can produce all type of standard building blocks by changing mould. 1,Multi-holes block and hollow block . 2,Ceram site heat preservation block. 3,Composite heat preservation concrete block The above production come with good heat preservation performance, and it meets the new national energy conservation policy. |
The Simple automatic brick making machine Production line
Batching Plant: This is the starting point of block making productione process. It consists of two loading bins and one weighing bin. It also contains blet conveyers to convey materials from loading bins to weighing bin. Batching and weighing is done by PLC control. We can load three different types of material into the loading bin.
Concrete Mixture Machine: All the ingredients are mixed in this mixture machine. The mixing time and speed is controlled by PLC. The inbuilt water pump adds water to the mix automatically, as per requirement.
Conveyer Belt: When the Batching plant’s weighing bin trips according to the PLC control, the material comes to this conveyer belt. The material is then carried to the Mixture Machine.
Block making machine:This is the key of the production line.It can press the mixed material.It can make various hollow block,solid brick,paver brick and kerbston.
Stacker:Stacker is used to lay the block automatically,it is high effiicent and labor saving
Main Specification and Productivity
| cycle Time | 15-20(s) | Total Power | 38.1(kw) |
| Vibration Type | hydraulic vibration | Vibration Force | 95KN |
| Gross Weight | 10500(kg) | Vibration Frequency | 3800-4500(Times/sub) |
| Pallet Size | 900×840×25(mm) | Machine Size | 9800×3600×2800(mm) |
| Production per Mould | 8pcs/M(390x190x190mm) 18pcs/M(240x115x90mm) 40pcs/M(240x115x51mm) 28pcs/M(200x100x60mm) | Production/8hours | 11520—15360pcs(390x190x190mm) 29800—39450pcs(240x115x90mm) 56000—75800pcs(240x115x53mm) 40320—53760pcs(200x100x60mm) |
Brick sample Picture
here is some sample for your reference, the mold can customized by your requirement.
Main Material:
formula 1:8-10% Cement,30%-40% sand,50-60%stone
Formula 2:8-10%cement,30-40%sand,50-60% fly ash
Also the material can be steel slag, coal ash, industrial waste and so on
If you have any question, please feel free to contact me.
