Automatic Plastic Lids Thermoforming Machine
- Ningbo
- T/T Credit Card
You May Like
-
SP510/580 plastic cup lid thermoforming machine
-
Automatic Plastic Thermoforming Machine, pressure BOPS forming machin
-
SP510/580 Automatic Air Pressure Plastic Thermoforming Machine
-
SP510/580 full-automatic plastic thermoforming machine
-
SP510/580 Plastic Vacuum Thermoforming Machine
-
SP510/580 Plastic Lid Cover Thermoforming Machine
Product Details
| Condition | New | Product Type | Other, lid, box, cover, spoon, blister | |
| Place of Origin | Zhejiang, China | Brand Name | Sinoplast | |
| Model Number | SPBG-400A | Voltage | 380V/50H, 3P | |
| Power(W) | 5KW | Dimension(L*W*H) | 2.7X0.83X1.45m | |
| Weight | 1200kg | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
I. Usage:
This machine is specially designed for making disposable HIPS/PVC/PET lids for plastic/paper cups, mini soup spoons, trays for medicine and etc.
II. Main Features:
1. This machine adopts sheet roll feeding, heating, molding, hole or cross punching, trimming, finished products transmission automatically, which saves labor and avoids product pollution during the production.
2. This machine is controlled by PLC with interface, which is easy operation and maintenance.
3. The journey of this machine is adjustable, and easy to change the moulds for different sizes of products.
In a word, this is a perfect machine with small workshop requires, less electricity consumption, less labor invests, less waste sheet appears, but high output, favorable price, easy operation and maintenance.
III. Main Technical Parameter:
Model | SPBG-400A |
Suitable Material | PS/HIPS/PVC/PET |
Journey Range | 30-160mm |
Max Forming Area | 400×160mm |
Max Forming Depth | 32mm |
The Power of Heater | 1.5KW*2pcs |
Total Power | 4.6KW |
Required Sheet Width | 340mm |
Required Sheet Thickness | 0.15-0.5mm |
Air Pressure | 0.4-0.7MPa |
Air Consumption | 0.6-0.8m3/min |
Water Consumption (recycle) | 60 liters/hr |
Punching Frequency | 8-32 times/min |
Total Power of Electric Source | 380V 50HZ 4.5KW |
Weight | 800Kg |
Dimensions | 2700×830×1450mm |
IV. Some Thermoforming Moulds:
V. Some Thermoforming Samples:
Any more information, please don't hesitate to contact with Ms. Maggie Lin:
Skype: maggielam718
Trade Manager: sinoplast2013
Whatsapp/Viber/Mobile: +86-13958816227
