Geophysical Resistivity Water detector for Underground Water Detecting

Utilizing the apparent resistivity parameters, this water detector is widely used in hydrology, environmental protection, engineering geophysical exploration, metal and non-metal mineral resources exploration.
This water detector also applies to electrical prospecting such as vertical electrical sounding, electrical profiling, charging method and spontaneous potential method, etc. On ground and in trench.

Main Features:

This water detector has such features as microcomputer controlled, direct-reading resistivity, various electrode arranging mode, data protection against power-failure.

Main Specification:

Maximum power supply voltage: 700V

Maximum power supply current: 3A

Voltage measuring range: ±3000mV

Voltage measurement accuracy: ±1.5%, ±0.1mV

Current measuring range: 0.1mA~3000mA

Current measurement accuracy: ±1.5%, ±0.1mA

Spontaneous potential compensation range: -1000mV~+1000mV

Instrument input impedance: >30M ohm

Working temperature: -10C Celcius ~50C Celcius

Volume: 244*154*237mm

Accessories Include:

No.	Description	Quantity	Picture
1	Battery case	4 Pcs
2	Alluminium case	1 Pc
3	Electrode	4 Pcs
4	Covered wire	1000 m
5	Brass wire	400 m

Use aluminium case for the water finder , and use wooden case to pack all accessories and the meter.

Dimension: 680*640*580mm

Weight: 57KG

Professional Mechanical & Electrical Equipment manufacturer in China.
With high quality products, competitive price and professional services.
Our products include:
1)Geological Exploration Instruments
2)Seismic Instruments
3)Drilling Machine
4)Well Logging System
5)Element Analysis Instruments

Hope there will be a chance for us to have a cooperation with each other, I believe our professional products and services will make you satisfied and bring mutual benefits to both sides of us.

More detailed informtion you can visit:
