2D Res Imaging Layout Terrameter Multi-Electrode 2D Water Detection
- Shanghai /Chongqing
 - T/T Credit Card

You May Like
-


500m Underground Water Detector Deep Water Detection 500m Water Finder
 -


New!!! Hot!!! Undergroud Water Detection /Water Finder /Water Detector 100-500m
 -


500M Underground Water Detector Underground Metal Detector
 -


Water Finder Terrameter Multi-Electrode 2D Resistivity Image
 -


DJF-2 Metal Detector Metal Detector Underground Mineral Detection
 -


Electric Meter 2D Tomograph Imaging System 300M Groud Water Detection Water Finder

Product Details
| Place of Origin | Chongqing, China | Brand Name | GOLD | |
| Display Type | Analogue and Digital | Accuracy Class | ±1% ± 1LSB | |
| Operating Temperature | -20℃~+60℃ | Dimensions | 270mm X 246mm X 175mm |
Product Description
2D Res Imaging Layout Terrameter Multi-Electrode 2D Water Detection
Welcome To Gold Team
Main Applications
• Transmitting unit and receiving unit are of all-in-one design, portable and lightweight.
• Super high-power, high anti-interference performance and precision: up to 6600w (1100v×6A) power, 48Vp-p voltage range ensures to get a good result in a area with high resistance.
• Automatically achieving compensation of self-potential, drift and electrode polarization, up to ±10V.
• Receiving unit support transient over-voltage protection, transmitting unit supports over-voltage protection, over-current protection and AB open-circuit protection.
• For general resistivity and IP survey function, 9 types of electrode arrays are available. Electrode distance (namely “Program”) can be inputted or called. Geometric factor K can also be generated automatically or calculated manually.
 • For multi-electrode 2D resistivity imaging, up to 18 electrode arrays are available. It could scanning measure according to fixed section (including AMNB, ABMN, AMBN, AMN, MNB, A-MN-B, Sp M, Sp MN, charge M, charge MN) or continuous rolling scanning measure according to variable section (including A-M, A-MN, AB-M, AB-MN, MN-B, A-MN rectangle).
• Program: the program can memorize 100 groups of electrode distances, avoiding repetitive input. Or you just input a program Id and step to call the corresponding electrode distances.
• Earth resistance inspection: ground condition can be inspected at any time.
• Mass data storage: Up to 1GB capacity (extended) enable store 5,000,000 groups measuring data (including current, voltage, SP, Ro, Ms, metal factor, TH, R, J).
• All parameter and data are under power-failure protection; and thus data will not be lost even thought the system shuts down accidentally.
• USB port enables it to transfer data to computer.
Technical specification:
| WDJD-4 Res/IP Meter | |
| Receiving | |
| Voltage precision | If Vp≥10mV, ± 5‰ ± 1LSB; if Vp < 10mV, ±1% ± 1LSB. |
| Input impedance | ≥50MΩ |
| Apparent polarizability precision | ±1% ± 1LSB |
| SP compensation range | ±10V |
| Current channel | 6 A, ±0.4% ± 1LSB, 24 bit A/D |
| Current precision | If Ip≥ 10mA, ± 5‰ ± 1 LSB; if Ip < 10 mA, ±1% ± 1 LSB. |
| Suppression | ≥80dB for 50Hz industrial frequency (common mode interference or differential mode interference). |
| Transmitting | |
| Max transmitting power | For general Res/IP sounding, 6600W. For multi-electrode Res imaging, 1125W, limited by WDZJ-4 switcher For Res cable, 1350W For IP cable, 2400W  |
| Max voltage | For general Res/IP sounding, ±1100V (2200V peak to peak) For multi-electrode Res imaging, 450V DC (limited by WDZJ-4 switcher)  |
| Max current | For general Res/IP sounding, ±6A For multi-electrode Res imaging, 2.5A DC (limited by WDZJ-4 switcher  |
| Pulse width | 1~60s, duty ratio 1:1 |
| Others | |
| Display | 160 × 160 dot matrix LCD |
| Storage | ≤1GB |
| Working temperature | -10℃~+50℃, 95 %RH |
| Storage temperature | -20℃~+60℃ |
| Instrument power | internal 12V 9Ah rechargeable battery , lasts for 30 hours (or 12V external power supply) |
| Weight | ≤ 4.4 Kg |
| Dimension (L×W×H) | 270mm X 246mm X 175mm |
WDZJ-4  Switcher  | |
Max electrode connected  | 60 and 120 (for option)  |
Insulation impedance  | ≥500MΩ  |
Max working voltage  | 500VDC  |
Max working current  | 2.5ADC  |
Power supply  | Internal 7.4V 4AH rechargeable lithium battery, last for continuously 25 hours work  |
Working temperature  | -10°C~+50°C  |
