Oil Boom WGV900
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Hua hai | |
| Model Number | WGV900 |
Product Description
The solid float PVC boom is the important equipment used for preventing spilled oil on waters from diffusion and transfer. It is widely used for long-term deployment on waters such as open seas, bays, harbors, wharfs, rivers, oil platform, oil-refining plants, oil piers, oil storage and also for emergent use in oil spilling accidents
Features
- 1. Made of the high strength fabric coated PVC on its two sides, having excellent resistance to oil and ageing.
- 2. The solid float have a large capacity of buoyancy and excellent wave and steadiness
- 3. The boom body is provided with a pulling rope, a strengthening ribbon and tensile ballast chains serving as elements to withstand forces and has tensile strength
Customers can choose different types for different needs, and we can supply customers with technical materials and special support .
Item | WGV600 | WGV700 | WGV800 | WGV900 | WGV1000 | WGV1100 |
Overall Height (mm) | 600 | 700 | 800 | 900 | 1000 | 1100 |
Freeboard (mm) | 180 | 260 | 250 | 330 | 325 | 320 |
Draft (mm) | 320 | 400 | 410 | 540 | 650 | 770 |
Standard Section Length (m) | 20,15,10 | |||||
Max. Tensile Strength (KN) | 20 | 40 | 55 | 65 | 75 | 85 |
Weight (kg/m) | 3.7 | 6.2 | 7.1 | 8.4 | 9.3 | 9.5 |
Buoyancy to Weight Ratio | 3.9 | 5.6 | 4.9 | 6.2 | 5.6 | 5.5 |
Efficient in Wave up to (m) | 0.5 | 1 | 1.5 | 1.8 | 2 | 2 |
Survival Condition (m/s) | 10 | 15 | 15 | 18 | 18 | 20 |
Stable in Current up to (Kn) | 1 | 1.5 | 2 | 2 | 2.5 | 2.5 |
20m Packing Size (m) | 1×1×0.6 | 12×1×1 | 1.3×1.1×1.1 | 1.4×1.5×1.2 | 1.4×1.6×1.3 | 1.4×1.7×1.4 |
PVC fabric | |||
1 | Tensile strength (N/cm) | Radial Direction | 485 |
2 | Warp Direction | 395 | |
3 | Elongation at break (%) | Radial Direction, | 10 |
4 | Warp Direction, | 15 | |
5 | Load at break (N) | Radial Direction, | 19 |
6 | Warp Direction | 20 | |
7 | Peeling load(N) | 16 | |
8 | Thickness(MM) | 0.7-0.9 | |

Qingdao huahai environmental protection industry Co., Ltd is located in the center of haibin industrial zone in Qingdao, China, which covers a total land of 92,713 square meters and has about 30,000 square meter construction facilities and 500 employees, including 120 technical engineers.
In 1990, the company successfully developed series oil spill response equipments, including oil containment booms, oil skimmers etc. In 1994, it was renamed Qingdao Huahai Environmental Protection Industry Co., Ltd, which developed rubber dams in 1996 and took the lead in obtaining the ISO9002 Certificate in 1998. In 2000, Huahai introduced new equipments and advanced technology to improve productivity. In 2008, Huahai invested 3 million RMB in production of oil sorbent mats and took part in the operation to clean enteromorpha prolifera from the water area in Qingdao where the 29th Olympic Regatta and Beijing Paralympic Sailing Event were held.
Huahai owns entire production lines of rubber dam and oil spill response equipments, mainly including skimmers, oil booms, storage facilities, oil spill monitoring systems and oil spill recovery boats etc.Huahai has six branches currently and keeps the trend of group development under the circumstance of blue economy.
