Home > Products > Turning center > Cnc Lathe Slant CNC150B Cnc Turning Center and Lathe Machine Price

Cnc Lathe Slant CNC150B Cnc Turning Center and Lathe Machine Price

FOB Price

US$ 5,000 - 50,000 / Set

1 Set(Min. Order)

Port qingdao port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Turning Center
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	150mm	Place of Origin	Shandong, China
Brand Name	HaiShu	Model Number	CNC150B
Voltage	380v 50hz	Power(W)	3.7kw
Dimension(LWH)	2700/3000/3500x1650x1900	Weight	3200kg
Certification	ISO9001 CE TUV	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

cnc lathe slant CNC150B cnc turning center and lathe machine price

CNC(B)Series single spindle single turret CNC turning center

No.	Item	Unit	specifications
No.	Item	Unit	CNC150B
1	Max.rotation diameter on lathe’ body	mm	150
2	piece lengt	mm	750/1000/1500
3	Max.turning diameter	mm	100
4	Spindle nose type and code	mm	A6
5	Hydraulic chuck	mm	Φ80 (4")
6	Front spindle bore taper		1:20
7	Spindle bore	mm	38
8	Spindle form		Servo spindle unit
9	Servo spindle speed range	rpm	0-4000
10	X/Z Rapid traverse	mm/min	40000
11	Main servo motor power	kW	3.7
12	C-axis(Turret power axis) motor power	kw	2.2
13	X/Z-axis motor max.torque	N.m	6
14	Y-axis travel(optional)	mm	+20/-20
15	Power specifications	v	380±10%. 50Hz±1Hz
16	Turret transfer time (one station)	s	1.6(12)
17	Turret transfer repeat positioning accuracy	mm	0.005"
18	X-axis travel	mm	100
19	Z-axis travel	mm	1100/1350/1850
20	C-axis(Turret power axis) max.speed	rpm	4000
21	Hydraulic servo turret form		Horizontal 12-station servo power turret
22	Turret cylinder clamping force	kg	2350
23	Turret hydraulic power source	kg/cm²	30
24	Power tool holder specification		VDI30 DIN5480
25	Tailstock sleeve diameter/ travel	mm	45/100
26	Tailstock tapered bore taper	Morse	3#
27	Tailstock form (programming optional)		Electric drive
28	Tailstock sleeve form		Hydraulic drive
29	Knife handle size	mm	16×16
30	Net weight	kg	3200
31	Size(L×W×H)	mm	2700/3000/3500×1650×1900

If you are interested in cnc lathe slant CNC150B cnc turning center and lathe machine price, welcome to leave a message or send the inquiry to understand the details of machine.
