Samsung SMD 3 Inch 5W led recessed downlight
- 1000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
-
4 Inch 10 watt surface mounted round downlight led
-
new 85lm/w CRI>83 Samsung smd 60w high power round led downlights adjustable
-
85lm/w Samsung smd 38W led adjustable shopfitting
-
85lm/w CRI>83 48W Samsung smd led adjustable shopfitting
-
85lm/w Samsung smd 38W round shape led downlight
-
20W Samsung SMD rectangular recessed downlight led
Product Details
LED Light Source | Samsung 5630 LED | Warranty(Years) | 3 | |
Input Voltage(V) | AC85-265V | Lamp Power(W) | 5 | |
Lamp Luminous Flux(lm) | 400lm±50lm | Lamp Luminous Efficiency(lm/w) | 80 | |
Color Temperature(CCT) | Other, 3000k-3500k, 4000k-4500k, 5500k-6500k | Working Temperature(℃) | -40, 60 | |
Working Lifetime(Hour) | 35000 | Lamp Body Material | Other, Aluminum alloy, PC | |
IP Rating | IP44 | Certification | CE | |
Model Number | NGE-SMD01-D5W3 | Place of Origin | Guangdong, China | |
Brand Name | NGE |
Product Description
Specifications
SMD led recessed downlight:1. uniform light, no flare
2. Samsung SMD,>100lm/w, CRI>80.
3. 3 years warranty
4. CE and RoHS
Product Features for Samsung SMD 3 Inch 5W led recessed downlight:
1. LED: High Brightness Samsung LED, light efficiency >100lm/w, CRI>80;
2. Excellent driver: Conversion efficiency above 85% and power factor >0.90;
3. Perfect light: Used low power SMD LED, uniform light and no flare;
4. Thermal technology: Aluminum radiator inside and PC outside;
5. Certificate: CE approval and RoHs compliant;
6. Warranty: 3 years.
.
Product pictures of Samsung SMD 3 Inch 5W led recessed downlight:
Technical parameters of Samsung SMD 3 Inch 5W led recessed downlight:
Product Name | LED Downlight |
Item Number | NGE-SMD01-D5W3 |
Rated Power | 5W |
Input Voltage | AC85-265V 50-60Hz |
Power Factor | >0.9 |
LED Type | Samsung SMD LED |
LED Quantity | 10PCS |
Luminous Flux | 400±50LM |
Color Temperature | 3000-3500K,4000-4500K,5500-6500K |
CRI | Ra>80 |
Product Size | φ125*H77mm |
Cutout | φ90mm |
Main Materials | Aluminum alloy and tempered glass |
Working Temperature | -40~60°C |
Lifetime | >35,000hours |
Warranty | 3 years |
Certificate | CE,RoHS |
Series product of Samsung SMD led recessed downlight:
Item No. | Watt | Input Voltage | Lumens | Size | Cutout | PF |
NGE-SMD01-D5W3 | 5 | AC85-265 | 400lm±50lm | φ125*H77mm | φ90mm | >0.90 |
NGE-SMD01-D8W4 | 8 | AC85-265 | 640lm±50lm | φ140*H93mm | φ120mm | >0.90 |
NGE-SMD01-D10W5 | 10 | AC85-265 | 800lm±100lm | φ180*H95mm | φ150mm | >0.90 |
NGE-SMD01-D12W5 | 12 | AC85-265 | 960lm±100lm | φ180*H95mm | φ150mm | >0.90 |
NGE-SMD01-D15W6 | 15 | AC85-265 | 1200lm±100lm | φ190*H95mm | φ170mm | >0.90 |
NGE-SMD01-D18W6 | 18 | AC85-265 | 1440lm±100lm | φ190*H95mm | φ170mm | >0.90 |
NGE-SMD01-D15W8 | 21 | AC85-265 | 1200lm±100lm | φ230*H100mm | φ200mm | >0.90 |
NGE-SMD01-D20W8 | 24 | AC85-265 | 1600lm±100lm | φ230*H100mm | φ200mm | >0.90 |
Certificates of Samsung SMD led recessed downlight :
The manufacturer of LED downlight
NGE Technology Limited is a professional indoor LED lighting manufacturer and solutions provider.
We are specialized in the LED shop lighting, office Lighting, commercial lighting, LED industrial lighting and residential lighting research and manufacture. Especially, LED shop light, LED tube, LED Panel light, L ED downlight, LED high bay, LED floodlight and LED bulb products are most popular products for us.
NGE Technology owns more than 180 experienced workers,15 persons' R&D team and 8000 square workshop. It is equiped with auto SMT machines, reflow-soldering machine, integrating sphere, goniophotometers machine and inspection instruments, etc.
NGE Technology endeavors to develop new LED lighting products. Our expert R&D team have abundant knowledge of electronic technology, structure technology, thermal management as well as optics design. Almost all of our products are CE certificated and RoHS compliant, and our LED Shop light are UL, PSE, SAA and C Tick approved.
NGE Technology has an excellent overseas sales and after-sales team. NGE products are very popular in Europe, America, Australia, Japan, Middle East and Southeast Asia market now.
We have successfully achieved over 50% annual growth in the turnover in the past 3 years. The turnover in 2012 is estimated to be 12 million US dollars. Let's work together to devote to the new, green and eco-friendly cause for the world.
